Insert Ball Bearing(UC312)

Application: Auto
OEM No/Model: UC312
Market Type:After Market
FOB Price: Inquiry For It?
Payment Terms: L/C, T/T
Minimum Order: 100 Piece/Pieces

Contact Supplier no sign-up required

Add to Favorites

Product Details

Company Profile

Quick Details

Place of Origin:
Zhejiang, China (Mainland)
Delivery Port:
Ningbo,Shanghai
OE Experience:
No

Product Name:Insert Ball Bearing(UC312)

Insert Ball Bearing(UC312)

Application

Auto

Product Description:

OEM No/Model: UC312

InserT ball bearing unit is combination of an insert bearing,seal and a housing of high-grade cast iron or pressed steel.

1-Construction:Insertbearing unit are composed of insert bearing installed in a special housing.The spherical fit of the outside diameter of the insert bearing and the inside diameter of the housing accomodates misalignments.

2-Production Range:

Bearing No.	Dimensions	mm								ratings	ratings	Weight
	Dimensions	in.								N	N	(kg)
	d	D	B	C	S	S1	G	d3	F	N	N	(kg)
UC311	55	120	66	34	25	41	12	M12×1.5	9.2	55050	41910	2.07
UC311-32	2	4.7244	2.5984	1.3386	0.984	1.614	0.472	1/2-20UNF	0.362			2.25
UC311-33	2-1/16											2.18
UC311-34	2-1/8											2.12
UC311-35	2-3/16											2.04
UC312	60	130	71	36	26	45	12	M12×1.5	9.8	62880	48600	2.60
UC312-36	2-1/4	5.1181	2.7953	1.4173	1.0236	1.772	0.472	1/2-20UNF	0.225			2.75
UC312-37	2-5/6											2.67
UC312-38	2-3/8											2.58
UC312-39	2-7/16											2.50
UC313	65	140	75	38	30	45	12	M12×1.5	10.5	72210	56680	3.25
UC313-40	2-1/2	5.5118	2.9528	1.4961	1.181	1.772	0.472	1/2-20UNF	0.413			3.34
UC313-41	2-9/16	5.5118	2.9528	1.4961	1.181	1.772	0.472	1/2-20UNF	0.413			3.24
UC314	70	150	78	40	33	45	12	M12×1.5	11.1	80100	63480	3.89
UC314-42	2-3/8	5.905	3.0708	1.5784	1.299	1.772	0.472	1/2-20UNF	0.437			4.11
UC314-43	2-11/16											4.00
UC314-44	2-3/4											3.90
UC315	75	160	82	42	32	50	14	M14×1.5	11.8	87250	71670	4.72
UC315-45	2-13/16	6.2992	3.2283	1.6535	1.26	1.969	0.551	9/16-20UNF	0.465			4.99
UC315-46	2-7/8											4.85
UC315-47	2-15/16											4.76
UC315-48	3											4.63
UC316	80	170	86	44	34	52	14	M14×1.5	12.5	94570	80350	5.55
UC316-49	3-1/16	6.6929	3.3858	1.7323	1.339	2.047	0.551	9/16-20UNF	0.492			5.72
UC316-50	3-1/8											5.58
UC316-51	3-3/16											5.49
UC317	85	180	96	46	40	56	16	M16×1.5	13.1	102050	89520	6.67
UC317-52	3-5/16	7.0866	3.7795	1.811	1.575	2.205	0.63	5/8-20UNF	0.543			6.89
UC317-53												6.76
UC317-55												6.44
UC318	90	190	96	48	40	56	16	M16×1.5	13.8	110810	100760	7.56
UC318-55	3-7/16	7.4803	3.7795	1.8898	1.575	2.05	0.63	5/8-20UNF	0.543			7.67
UC318-56	3-1/2	7.4803	3.7795	1.8898	1.575	2.05	0.63	5/8-20UNF	0.543			8.7
UC319	95	200	103	50	41	62	16	M16×1.5	14.7	120510	103750	9.03
UC319-58	3-5/8	7.874	4.0551	1.9685	1.614	2.441	0.63	5/8-20UNF	0.579			8.85
UC319-59	3-11/16											8.66
UC319-60	3-3/4
