Inch Tapered Roller Bearing 07098/07196
Tapered Roller bearings are generally used to support combined load mainly consisting of radial load.
Their cups are separable for easy assembling, during mounting and using, radial clearance and axial clearance can be adjusted and preloaded mounting can be made.
Quality Certification: ISO 9001:2000, ISO 14001:2004, ISO/TS16949:2002
The tapered roller bearing life test for 500 hours,and enjoy great reputation in America,Japan,Southeast Asia and Europe.
Bearing material: Chrome steel (International: Gcr15/USA; AISI 52100/GERMAN: DIN100Cr6/JAPA: JISSUJ2) and carbon steel
Tolerance standard: GB/T307 (ISO492)
Hardness: HRC60-HRC65
Single color box or tube or oil paper package
Bearing No.
Dimension(mm)
Inner Ring
Outer Ring
d
24.981
07098
07196
D
50.005
Basic load rating
T
13.495
Dynamic (Cr)
Static (Cor)
B
14.260
26.7
28.8
C
9.525
Limiting speed
Rmin
1.6
Grease
Oil
rmin
1.0
7900
11000
Inch
Bearing steel
Life test for 500 hours
Can be bear a one-way axial load
ISO 9001:2000, ISO 14001:2004, ISO/TS: 16949
