Certificate: DOT,ECE, REACH,NEW LABEL, S-MARK, ISO90001, SONCAP, LATU, INMETROP,etc
Five ribs with four wide, straight grooves for precise handling and outstanding traction.
Solid shoulder helps to minimize shoulder wear and improve cost per mile.
Advanced cool-running tread compounds reduces heat generated and increases irregular wear resisitance resulting in higher mileage.
| Index |
Depth (mm) |
Rim |
Diameter (mm) |
Width (mm) |
Max. Load Capacity at Cold Inflation Pressure |
|||||
| Single | Dual | |||||||||
| 11R22.5 | H/16 | 148/145M | 15.0 | 8.25 | 1054 | 279 | 3150 | 850 | 2900 | 850 |
| 12R22.5 | H/16 | 150/147L | 15.5 | 9.00 | 1085 | 300 | 3350 | 830 | 3075 | 830 |
| 12R22.5 | J/18 | 152/149L | 15.5 | 9.00 | 1085 | 300 | 3550 | 930 | 3250 | 930 |
| 385/55R22.5 | L/20 | 158L(160K) | 15.0 | 12.25 | 996 | 386 | 4500 | 900 | - | - |
| 295/60R22.5 | J/18 | 150/147L | 15.0 | 9.00 | 926 | 292 | 3350 | 900 | 3075 | 900 |
| 315/60R22.5 | J/18 | 152/148M | 15.0 | 9.75 | 950 | 313 | 3550 | 900 | 3150 | 900 |
| 295/80R22.5 | H/16 | 150/147 M | 15.0 | 9.00 | 1044 | 298 | 3350 | 830 | 3075 | 830 |
| 295/80R22.5 | J/18 | 152/149M | 15.0 | 9.00 | 1044 | 298 | 3550 | 900 | 3250 | 900 |
| 315/80R22.5 | J/18 |
154/151M (156/150L) |
16.0 | 9.00 | 1076 | 312 | 3750 | 830 | 3450 | 830 |
