Y505-A Optical Dissolved Oxygen Sensor:
Y505-A is developed for cost sensitive aquaculture applications. With build-in NTC temperature sensor for compensation and rugged metal sensor housing, it can be easily integrated with any data acquisition equipment and wireless transmission systems for real time aerator control.
Y505-A Features:
Range | 0-20mg/L or 0-200% Saturation |
Response Time | 40 Sec |
Housing IP Rating | IP68 |
Accuracy | 3% |
Drift | <1% per year |
Working Temperature Range | 0 ~ 50 |
Temperature Accuracy | ±0.5 |
Interface | Support RS-485 MODBUS protocols |
Installation thread | M22*1.5 mm |
Power Requirements | DC 6~12V +/-5% current <50mA |
Temperature Sensor Type | NTC |
Sensor OD | 23mm |
Sensor Length | 188.3 mm |
Cable Length | 10m standard; 5m, 15m, and 30m optional |
Calibrations | Support one point and two-points calibrations |
Sensor Cap Lifetime | 1 Yearat normal use |
Body materials | POM and Stainless steel |
