Liquid Level Switches
Optomax Industrial Glass Series
FEATURES
Liquid level switches that can detect almost any liquid type; oil or water based
Suitable for harsh environments; robust stainless steel housing and glass tip
Choice of mounting threads
BENEFITS
High power
Industrial supply voltage
Direct load drive
TECHNICAL SPECIFICATIONS
Supply voltage (Vs) 4.5VDC to 15.4VDC
or 8VDC to 30VDC
Supply current (ls) 2.5mAmax.(Vs = 15.4VDC)
or 7.5mAmax.(Vs = 30VDC)
Output sink and source current (lout) 1A
Operating temperature1 Standard: -25 to +80
Extended: -40 to +125
Storage Temperatures Standard: -30 to +85
Extended: -40 to +125
Operating pressure 0 to 85 bar
Housing material Stainless steel with glass tip
Sensor termination 20AWG, 250mm PTFE wires, 8mm tinned
ORDER INFORMATION
Generate your specific part number using the convention shown below. Use only those letters and numbers that correspond to the sensor and output options you require omit those you do not.
