2. working parameters:
Pressure range: 50kpa-400kpa
overpressure: 1.2times
Precision range: ±2%@ -40~135 degree
Power supply voltage 5±0.25V
Output voltage 0.5~4.5V
The power supply can exceed to: 24V
Protect grade: IP55
EMI protection:
1. Working temperature -40~125 degree
2.compensated temperature -40~125 degree
3.response time 2.5ms
Precision:
temperature |
prcision |
-4010 | 3%-1.5%FS |
1085 | ±1.5%FS |
85125 | ±3%FS |
Output Temperature |
Resistance value |
-10±1.5 | 9.395k±0.38k |
20±1.5 | 2.499k±0.084k |
80±1.5 | 322.5k±7.5k |
