3. 5inch Bluetooth Car Kit With Back-Up Cam Support Patent

    • Application: Universial
    • OEM No/Model: Mc89
    • Market Type:After Market
    • EXW Price: Inquiry For It?
    • Other Price Term: FOB Shenzhen
    • Payment Terms: T/T
    • Samples: Charge
    • Minimum Order: 50Set/Sets

Quick Details

  • Voltage:

    12v

  • Power:

    7w

  • Warranty:

    1years

  • Sensor detect distance:

    100m

  • Display size:

    3.5inch

  • Support:

    SD Card (Max 8 G)

  • phonebook:

    500 contacts

  • Report caller ID:

    Yes

  • Camera color:

    CMOS

  • FM modulation:

    87.5-108 MHZ

  • Bluetooth Specification:

    Version 2.1

  • Support profiles:

    HSP/HFP 1.5 A2DP OPP

  • Camera range:

    100 meters

  • Display outgoing call number:

    Yes

  • Certification:

    CE/FCC/ ROSH/ PATENT

  • Features:

    bluetooth / 3.5inch Car mirror/ back up camera

  • Place of Origin:

    Guangdong China

  • Samples:

    Charge

  • Sample Price:

    129

  • Delivery Time:

    3-15 Working Days

  • Packing:

    10PCS/CTN N.W.: 9KG G.W.:9.8KG Measure: 35.6cm*37.7cm*32.2cm Product Size: 298mm*80mm*6mm Packing Box Size: 13.3cm*6cm*2.5cm

  • Delivery Port:

    Shenzhen

  • Max. Production Capacity:

    5000 sets per month

  • Export Ratio:

    91% - 100%

  • OE Experience:

    No

Product Name:3. 5inch Bluetooth Car Kit With Back-Up Cam Support Patent

3. 5inch Bluetooth Car Kit With Back-Up Cam Support Patent

Application

Universial

Product Description:

OEM No/Model: Mc89
3.5inch TFT Display Screen Bluetooth car kit Support SD Card

Features:
1. Built-in microphone with DSP (Digital Signal Processing) noise and echo cancellation
2. Two speakers so you can hear callers loud and clear
3. High quality 3.5" TFT LCD color display caller's ID and name
4. Display outgoing call number
5. Report caller ID (language optional)
6. Sync with your mobile's phonebook (500conacts)
7. Wireless backup camera, visual angle 120, waterproof design
8. Camera color CMOS (CCD optional)
9. FM modulation to transfer voice and music to car radio(87.5~108MHZ)
10. Wireless Earphone
11. Support display SD Card(song name and index)

Specification:
Bluetooth Specification: Version 2.1
Support profiles: HSP/HFP 1.5, A2DP, OPP
Camera range: 100 meters


Installation

1.Clip on the original car mirror. It does not need to destroy car decoration.


2.(1)Wireless back-up cameras are only wireless between the dash-mounted monitor and the camera at the back of the vehicle. The camera still needs to be wired in for power and to be turned on. Usually the camera will utilize the vehicle's reverse light circuit for both. The camera piggy backs on the reverse lamp's power, and conveniently the power only comes on when the vehicle is in reverse.


(2)Loosen the rear license plate bolts or screws and remove the license plate. Insert the license plate bolts or screws through the holes on the camera. You will be using the license plate fasteners to mount the camera. Align the license plate with the camera in position and bolt or screw the assembly to the vehicle.

(3)Determine the path for the cable that will run from the camera to the reverse lighting circuit. You can drill a hole or use the license plate light hole. If you are drilling a hole, check behind the area first and then insert the supplied grommet to prevent chaffing and weather penetration to the vehicle. Pass the cable through the grommet and run it to a reverse light.


(4)Remove the negative cable from the vehicle's battery and then remove the reverse light bulb from its socket. Splice the red wire from the camera onto the red wire that goes to the reverse light socket. Do the same with the black wire. You can just strip a quarter inch of plastic coating off the wire and wrap bare camera-originating wire around the stripped part. Cover with insulation tape.

(5)Replace the bulb and replace the negative cable to the battery. Turn on the monitor and adjust the angle of the camera so that the eye points to the rear. The barrel of the camera swivels.

FAQ
1  Will this item fits my car?
Our products will fit most standard carsDC12V- 14V)
2  Can it be shipped to my country?
We can ship items to any region of the world except military areas.
3  How long does it take to arrive?
Generally speaking we will arrange the shipment in 1-3 business days once the payment is confirmed, and we cooperate with world famous EMS for delivery, which enable over 90% of our customers to get most of our items within two weeks!
4  Do I need to pay custom duties?
The custom duties are charged by importing countries. Though we can not control this, we will help you to declare a lower value at customs. Therefore, most of our customers do not need to pay custom duties or just pay few. If you have special requirements for declared value, please explain to us when you place orders.
5  Warranty terms
We offer one full year warranty for all our products. In the warranty period, we would like to fix the problems for you. Note that product problems do not include man-made causes.
6  Refund Terms
(1) Situation One: you make an order and the payment is confirmed, but you change your mind before the goods are shipped out. You can apply for a full refund. But if the goods are shipped out, and arrived with fine quality there are no refund for personal reason.
(2) Situation Two: Because natural disasters and war happen, such as earthquakes, floods, tornadoes, tsunamis, wrecks, plane crash, etc, it will not be refunded.

(3)Situation three: Receiving a defective product, and you want a replacement, please tell us in 2 working days, we will replace a fine product for you, you need to send it back to us. Courier fees will be paid by both sides. What is more, no refund will be paid.
