K10 | QK3015 | YBD151 |
The substrate with high strength and resistance against plastic deformation,in combination with coating composed of MT-TiCN, thick layer of Al2O3 and TiN makes it suitable for steel roughing. |
P10 | QP1115 | YBC152 |
Thick TiCN and thick Al2O3 coatings improve the impact toughness and abrasion resistance, which makes it suitable for finishing and semi-finishing of steel at high speed. Cutting speed can increase by more than 25%, while the tool life can increase by more than 30% at the same cutting speed. |
P20 | QP1125 | YBC252 |
Comprising of thick TiCN and thick Al2O3 coatings, the grade has high capability against plastic deformation and good hardness of cutting edge. It is preferred grade for machining of steel from finishing to roughing. Under the same cutting conditions, the cutting speed can be increased by more than 25%, while the tool life can be 30% longer under the same cutting speed. |
K01 | QK3105 | YBD052 |
CVD coated grade, which is characterized by super fine grain and smooth surface, is the combination of hard substrate and coating (extra thick Al2O3 + thick TiCN ). The grade is optimized for best wear resistance when machining gray cast iron at high speed under dry condition. |
K10 | QK3110 | YBD102 |
CVD coated grade, which is the combination of hard substrate and coating (thick Al2O3 + thick TiCN ), shows excellent wear resistance and impact resistance when machining nodular cast iron at high speed. |
K10 | QK3015 | YBD152 |
CVD coated grade, which is the combination of hard substrate and coating (medium thick Al2O3 + thick TiCN), has good flaking resistance. It is suitable for turning of cast iron at high speed, and light intermittent cutting can be supported even at moderate speed. It is also suitable for milling of cast iron. |
K30 | QK3125 | YBD252 |
CVD coated grade, which is the combination of hard substrate and coating (medium thick Al2O3 + thick TiCN), achieves the balance between wear resistance and toughness. It is suitable for wet milling of cast iron,which requires toughness (such as nodular cast iron) at moderate or low speed. It is also suitable for intermittent Turning. |
P20 | QG7205 | YBG205 |
grade for finishing of stainless steel Suitable for relatively small workpieces which require high surface smoothness. Superfine TiAlN nano coating added with wear-resistant and heat-resistant rare elements has high hardness and excellent heat-resistance, providing effective protection for the cutting edge. Special coating technology ensures stronger combination of coating and substrate. It is suitable for extra finishing of stainless steel. |
P10 | QG7102 | YBG102 |
The combination of nc-TiAlN coating and fine grain substrate makes it suitable for turning of various materials and finishing and semi-finishing of high-temperature alloys. |
P20 | QG7202 | YBG202 |
nc-TiAlN coating and ultra-fine grain substrate makes it suitable for finishing and semi-finishing of various materials and turning of super alloy. |
P30 | QG7302 | YBG302 |
The combination of nc-TiAlN coating and tough cemented carbide substrate, which integrates security and wear resistance, makes it suitable for parting and grooving of various materials. |
|
