1.Cavity:single or two
2.Core:single or two
3.Mould steel:45#,718#,55#ect
4.Runner:hot/cold...
the structure of mould
Word-model structure, mould adopts the work P20 cavity and cores choose 2738, slider, or guide by sliding channel, insert 2316 or 718, guiding pole, lead sets, runner cover, pull material stem and reset pole adopts SKD, formwork adoption from standard for standard formwork. Good material corrosion resistance, toughness, thermal conductivity and hardness, made of polished easier, and save the production cycle, extended the die life, reduce the maintenance and repair time, reduce the cracking risk, improve the production efficiency.
Mold cooling system
The cooling system's design is a relatively numerous lock work, namely to consider cooling effect and cooling evenness, one should take account of the cooling system of the whole structure of the influence of mold cooling system to determine the specific location and size; Key parts such as dynamic model or insert cooling; Lateral spreads block and lateral cores of cooling; Cooling components design and cooling the selection of standard components. Our company in the mold design began to analyze these problems the way, the mould adopts the circulating water in the mold internal each place when we do the injection, reduce the flow cooling time, improve the production efficiency, and greatly reduce the production cost.
Name
plastic injection molding-Push fit pipe fitting mould
Plastic material
PVC,PPR,PP.PE,ABS,POM,PPH…etc
Steel of Cavity & Core
DIN 1.2316/ DIN 1.2738/DIN 1.2344 /M300/ 718/ P20..etc
Steel of Mouldbase
S50C.LkM standard…etc
Nos of Cavity
Customized
Hardness of Cavity & Core
42-45HRC
Hardness of Wear Parts
42-48HRC
Core pulling system
Motor /oil cylinder/ stripping plate, angel pin…etc
Mould Accessories
DME/HASCO Standard …
Cooling system
In core baffle cooling and in cavity plate chain drilling type cooling
Surface finish
Diamond polish,
Molding life
500,000-1,200,000shots
Runner
Cold or Hot
Delivery time
35-75work days
Packing
wooden case
Search
Buyer search the internet to find the seller and the seller try to find the buyer
Negotiation
Quality-Price-Mould material-Delivery time-Payment-Technique requests
Down payment
Usually 30% before we start working
R and D
We offer customers the drawings for products and mould structure
Confirmation
We send the drawings to customer to confirm
Machining center
CNC milling machine-NC wire cutting-NC-EDM and so on
Testing
Testing the mould to make sure everything is ok
Confirmation
We send the sample to customer to check
Balance
Buyer send us the balance of the mould before shipping
Delivery
We send the mould to our customer by sea or by air as the demand of customer
