Product Name:Digital Portable Palm OTDR Meter Tester RY-OT4000 1210.00EUR

Digital Portable Palm OTDR Meter Tester RY-OT4000 1210.00EUR

Application

Car

Product Description:

OEM No/Model: AT35
Digital Portable Palm OTDR Meter Tester RY-OT4000 32/30dB 1310nm/1550nm


Highlights:
Language: English
100% original Manufacturer
OTDR Wavelength: 1310nm/1550nm Fiber Type: Single-Mode
Dynamic Range: 32/30dB


RUIYAN OTDR-4000 series portable optical time domain reflectometry (OTDR) is the latest FTTx optical fiber cable-based test instrument. It has light weight, elegant appearance, small size, easiness of installation and maintenance, high-capacity built-in battery. It provides multiple built-in test wavelengths and optical testing functions like visual fault locator (VFL). As a new product specially designed for FFTx network testing, it provides site technicians with the highest performance and upgrade services.

RY-OTDR4000 Palm OTDR Tester Features Advanced anti-reflective LCD, display interface is clearly visible in bright light(VFL)Visual fault location functionIt provides high-speed USB port, waveform file conversion and printing convenienceLong-lasting lithium battery, ideal for long-time outdoor construction workOnline upgrade function, users do not have to go back to original factory to upgrade the system.

Digital Portable Palm OTDR Tester Main functions
1. Fast automatic testAutomatic test function allows the user not to have to know more details about the equipment operation, test steps become very simple. User only needs to connect in the optical fiber, click Test button, then the instrument will automatically set optimal test conditions and eventually give accurate test results, such as the test curve and event lists.

2. Fast curve analysisIt can find out the event point or failure point in test curve and its location information quickly and accurately test curve, and list all event information in the circuit in the form of event list. This is very helpful for circuit maintenance personnel, not only improves the testing efficiency, but also eliminates the need to learn difficult background knowledge.
3. Powerful document managementIn addition to the ability to store, view, delete the files in the machine, it also provides PCL language-based laser or jet printers to print test reports. Besides, it also utilizes PC software to realize high-speed communications with PC via USB cable.
4. Convenient VFL functionWith visual IR VFL function, it can easily and quickly the locations of disconnecting points or big loss points in short-distance optical fibre links, so that the maintenance personnel could take measures in shortest time therefore saving a lot of time.
5. Manual test modeUsers can choose real-time test mode or average test mode according to the testing needs. Real-time test can fast test the dynamic change of optical-fibre links. It is mainly used for the connecting occasions requiring monitoring or observing optical-fibre links at real time.
6. Average test modeAverage test mode is used to withhold the noise in test curves to the most extent, therefore obtain more accurate testing results. In average test mode, the number of averaging tines will influence the effects of suppressing the noise in test curves. The bigger the number of time is, the effect the time is, but the testing time is to be extended accordingly. Therefore, user should set averaging time based on actual need.
7. Dead zone test modeIt is suitable for the test of ultra short-distance optical fibre.
