Product Name: Auto Diagnostic Tool AUTOBOSS V30 Auto Scanner
Function of AUTOBOSS V30 Scanner:
1. Read/Clear Diagnostic Trouble Codes (DTCs)
2. Retrieve Real-time Data stream
3. Perform Component Actuation and/or Functional Tests
4. Perform ECU Coding/Programming
5. Perform Service Functions
6. Perform "Quick Test" on all or common vehicle systems
Feature of AUTOBOSS V30 Scanner:
1. Live data graphic display
2. Full component activation
3. Read & change ECU coding
4. Setting of adaptation values
5. CANBUS function supported
6. Internet update function
7. HYUNDAI immobilizer
8. Testing report saving function
9. VOLKSWAGON immobilizer III
10. Coding of the new control modules
11. NISSAN idle speed self learning function
12. Multi-language for international market demand
13. Hand-held independent operation, supporting PC link
14. Educational teaching for all car models.
15. Interconnecting teaching and diagnostic, two function in one
Support Car List:
1. European Cars:
LANCIA LANDROVER PEUGEOT AUDI FORD SEAT LADA Porsche
RENAULT FIAT VOLVO
SMART BMW GAZ
MINI VAZ BENZ
OPEL SAAB CITROEN VW
2. Asian Cars:
DAEWOO SUBARU MITSUBISH
NISSAN HONDA KIA
SUZUKI TOYOTA HYUNDAI
ISUZU MAZDA LEXUS
PERODUA PROTON SSANGYONG
3. American Cars:
FORD GM CHRYSLER Prutton
4. OBDII Cars:
OBDII ISO KWP VPW PMW CAN
5. Chinese Cars:
CHANGHE CHANA GREATWALL
FOTON GEELY CHERRY FUDI
Covering latest and early model car of Asian, European, American and domestic.
-Many car models have covered 80% -90% function of the original scanner
-Supporting CAN- BUS diagnosis of Volkswagen / Audi, Ford, Mazda, Nissan, Hyundai / KIA
-Built-in high / low speed CAN- BUS and single CAN- BUS
-Making all CAN- BUS systems available with only one connector
-Supporting 5 OBDII protocols and 9 modes
-Nissan idle speed adaptation
-Immobilization system generation III adaptation of Volkswagen.
Many car models have covered 80% -90% function of the original equipment. Some car families are no difference to the original equipments.
VW / Audi:All CAN- BUS system after 2005
GM: The testing function has covered 90% of the GM original equipment
Toyota: The actuation function is the same to the original equipment
Nissan: Covering 95% function of the original equipment
Honda: Only system selection is needed for diagnostic scanning
Hyundai / KIA:More than 90% function coverage of the original equipment
All systems of all car models are available
Opel: 17 models can be tested and the basic function makes no difference of the original equipment
Specification AUTOBOSS V30 Scanner:
CPU |
SAMSUNG ARM9 2410A, 200MHz; |
Memory | 64M; |
Flash card | SD card, 1G |
Display | 5. 6" VGA (640×480) ultra bright TFT; |
Power supply | DC 8~12V, AC 110~250V 50Hz; |
Port | Diagnosis port, COM port, USB port, Power Port; |
Operating system | WINDOWS CE; |
Storage temperature | -30~90ºC; |
Working temperature | -10~80ºC; |
Humidity | <90%. |
Network output port |
6,Aviation plug |
Network connection | RS485 |
Signal testing port | 6 |
Communicating interface with PC | RS232 |
Power supply | DC, 8-12V; AC, 110-250V 50Hz |
Network input port |
1,Aviation plug |
Network output port | 1,Aviation plug |
Network connection | RS485 |
Signal testing port | 6 |
Communicating interface with V30 | RS232 |
Diagnostic connector with V30 | OBDII-16 |
Power supply |
