120m3/H Loading Capacity Wheel Belt Muck Loader

    • Market Type:OE Market
    • FOB Price: USD 15000
    • Payment Terms: L/C, T/T
    • Minimum Order: 1Set/Sets

Quick Details

  • Output Power:


  • Length:


  • Width:


  • Height:


  • Designed Capacity:

    1000 Sets Per Year

  • Main Raw Material:

    Steel, Copper, Iron

Product Name:120m3/H Loading Capacity Wheel Belt Muck Loader

120m3/H Loading Capacity Wheel Belt Muck Loader



Product Description:

80m3/h Loading Capacity Wheel Belt Tpye Underground Mucking Loader
Product Description

The multifunctional mine muck machine is a new type of loader developed to improve labor intensity and work efficiency. The machine can directly transport rocks to the conveyor belt. The machine adopts full hydraulic control mode, which is simple and convenient to operate. The gantry frame of the machine is detachable and non-cut, which is convenient for installation in the well. In addition, the height of the rear unloading can be adjusted according to the customer's own needs. The machine is equipped with an adventure device to solve the danger of manual exploration. This machine can be used in a cave below 2.2 meters, and the loading capacity per hour is between 40-60m³.


Mine slag raking machine is mainly used for phosphate ore, aluminum ore, iron ore, copper ore, gold ore, silver ore, lead-zinc ore and other mines, hydropower, tunnel projects in narrow-space mining operations. And

transportation, construction and loading. The mining slag raking machine is a combination of a manipulator and a conveyor. The slagging and conveying and loading functions are combined into one. The production device adopts an electric full hydraulic control system. It has the characteristics of safety, environmental protection, low energy consumption, and high efficiency. It is an indispensable advanced mining equipment for mining enterprises and a substitute for labor and other machinery.


Model : ZWY120
Loading capacity m3/h : 120
Weight kg : 4280
Digging width mm : 3800
Digging height mm : 3000
Digging depth mm : 500
Digging distance mm : 1800
Gradeability ° : 5
Unloading height mm : 1750Can be heightened
Unloading distance mm : 2200Can be lengthened
Minimum turning radius ° : 5
Power kw : 18.5
Walking speed km/h : 1.45
Maximum passing size of material mm : 950×700
Wheelbase mm : 1900
Wheel distance mm : 1580
Adaptation dimensions m : 2.6×2.6
Product dimensions mm : 7000×2000×1900
