Product Name:Self-Propelled Modular Transporter （SPMT)

Self-Propelled Modular Transporter （SPMT)

Application

goldhofer

Product Description:

Parameters of self-propelled modular transporter  SPMT)
     Parameters of self-propelled modular transporter
The self-propelled modular transporteris a kind of high end product which is derived on the basis of hydraulic assembly trailer. The utility model is composed of a driving axle module transport vehicle and a power module unit (PPU). The module can be connected mechanically, and can be freely positioned, transporting goods up to ten thousand tons.
     Main assembly technical parameters
 1 power module unit technical parameters
   Length (mm)           3,770
   Width (mm)           2,980
  Height (mm)           850
 Lifting angle (DEG)           12
Self weight (kg)           6,000
 Engine manufacturer           MAN
 Engine type           D2876LUE604
 Engine power (kW/ RPM)           375/ 2000
  emission standard           Europe III
Fuel tank volume (L)           400
 Hydraulic tank capacity (L)           850
 Maximum operating pressure of drive system (bar)           410           Steering system maximum operating pressure (bar)           300
Electrical system (V)           28
   Remote control           Wire or radio




www.gasgoo.com




Presentation RQH Trailers is the Chinese market leader in the design and production of vehicles for abnormal road transport with payloads from 20 up to 1000 tonnes. In order to further build on this trend-setting position, RQH continuously strives to improve quality and service. The product range ...[Read More]
