Image for Cnc Lathe Machine

Cnc Lathe Machine

Application: metal working
Market Type:After Market
FOB Price: USD 123456
Other Price Term: TT
Payment Terms: L/C
Samples: Free
Minimum Order: 1Unit/Units

Contact Supplier no sign-up required

Add to Favorites

Product Details

Company Profile

Quick Details

Output Power:
7.5kw
Samples:
Free
Delivery Time:
In Stock
Packing:
The Metal Machine Can Be Loaded In Four Wooden Boxes, And Then Loaded In 1x40'Ft Container .
Delivery Port:
Shanghai
Max. Production Capacity:
3set
Export Ratio:
11% - 20%
OE Experience:
No

Product Name:Cnc Lathe Machine

Cnc Lathe Machine

Application

metal working

Product Description:

Hengshui Shengyong Heavy-duty Machine Tool Manufacturing Co.,Ltd specializes in the manufactures and sells of metalworking machines: vertical turret lathe,cnc lathe machine,Single column vertical lathe , Double column vertical lathe machine ,Heavy duty horizontal lathe machine, Gantry milling machine(Plano Miller), Gantry Planer Milling Machine, Roll turning lathe, Floor type boring lathe etc.If interested, please feel free to contact us.Best regards, Abby Shang

Double column Vertical Lathe machine of C5225/CX5225/CK5225

Technical specification
No	Title	C5225/CX5225/CK5225						Unit
1	Max.turning diameter	2500						mm
2	Max.height of workpiece	1600	2000	2200		2500	3000	mm
3	Max.weight of workpiece	10			20			t
4	Table diameter	2250						mm
5	Speed change of table	2~63						r/min
6	Max.torque of table	63						KN/min
7	Vertical travel of tool post	1000/1250						mm
8	Horizontal travel of tool post	1400						mm
9	Rotation range of tool post	±30°						Degree
10	Power of main motor	55						kw
11	Machine weight(About)	32~38						t
Notice:This technical parameters is for reference only, The contract are based on the standard of technology agreement.
