Image for GDYJ-503 Transformer Oil Breakdown Voltage Tester

GDYJ-503 Transformer Oil Breakdown Voltage Tester

Application: GOLD
Market Type:After Market
Price: Inquiry For It?

Contact Supplier no sign-up required

Add to Favorites

Product Details

Company Profile

Quick Details

OE Experience:
No

Product Name:GDYJ-503 Transformer Oil Breakdown Voltage Tester

GDYJ-503 Transformer Oil Breakdown Voltage Tester

Application

GOLD

Product Description:

GDYJ-503 Transformer Oil Breakdown Voltage Tester
Standard
1.GB-86 DeterminationMethod for Dielectric Strength of Transformer Oil.
2.IEC60156
Feature
1..The tester can test three cups of oil at the same time.LCD screen can display test procedure and test result.
2.All the human interaction operations complete by the rotating mouse.
3.It is very easy for customers to measure the breakdown voltage of all kinds of oil by GDYJ-503.
4.You can print the test result by the micro printer internal the tester.and upload the test data to PC from RS232 for data analyzing.
Technique index

Output voltage	AC 0~80KV
Make a choice and combination	at random between A,B and C cup
Rate of voltage rise	2KV/s±10%
Measuring precision	3 class
Times	1-6
Mixing time	0~99 second
data	Save 50 groups
Voltage limit setting for proof test	20KV----70KV
Hold time for proof test	0 minute -----10 minutes
Environment temperature	5-40
Relative humidity	80%RH
Size	420×380×410mm3 28KG
