OEM No/Model: LHQD
Air pallets and air bearing transporters are one of the most versatile pieces of air film equipment .
They are used in exactly the same way as conventional roller skates would be.
The Air pallets and air bearing transporters are simply placed underneath the load to be moved,air is applied,and the load is simply pushed to the required position.
Air pallets and air bearing transporters also called air caster, air powered moving casters, air bearing casters, air roller skates, air rollers, air moving skates, air powered heavy load moving equipment systems and so names.
Air pallets and air bearing transporters LHQD ,a kind of pneumatic device which can form a lubricating film of air between the load and floor surface,used to move heavy equipment on flat, non-porous ground.
Air pallets and air bearing transporters applicable scope:
Air pallets and air bearing transporters LHQD handling equipment under clean environment [clean room, clean room dedicated]
Air Pallets and Air Bearing Transporters LHQD features:
Air pallets and air bearing transporters LHQD on the ground friction is small, can be well protected ground;
Air pallets and air bearing transporters LHQD and maintenance simple, good safety performance;
Air pallets and air bearing transporters LHQD can be shipped according to the weight and volume of objects in combination, for large and small weight of transport;
Air pallets and air bearing transporters LHQD can be combined volume size, light weight, easy to carry or install;
Air pallets and air bearing transporters LHQD can be used alone, without jack, hand destroyed the top of the tie.
Air pallets and air bearing transporters Brand:LONGSHENG
Air pallets and air bearing transporters Model:LHQD
Air pallets and air bearing transporters Load:10-48T
Air pallets and air bearing transporters Warranty:1 years
Air pallets and air bearing transporters LHQD technical parameters:
Model |
Capacity |
Quantity of Air Cushion |
Size of Air Cushion |
Main Material of Air Cushion |
Height of Air Cushion |
Main Gas Supply Flow |
Pressure |
Main Pipe Length |
Vice Pipe Length |
Net Weight of Each Air Cushion |
(T) | (L×W×H,mm) | (mm) | (m3/ min) | (kg/cm2) | (m*quantity) | (m*quantity) | (kg) | |||
LHQD-10-4 | 10 | 4 | 380×380×50 | Aluminum 6061 | 40 | >3 | 7 | 30*1 | 6*4 | 8.5 |
LHQD-16-4 | 16 | 4 | 485×485×50 | Aluminum 6061 | 40 | >3.5 | 7 | 30*1 | 6*4 | 13 |
LHQD-20-4 | 20 | 4 | 540×540×50 | Aluminum 6061 | 40 | >4 | 7 | 30*1 | 6*4 | 17.5 |
LHQD-32-4 | 32 | 4 | 686×686×50 | Aluminum 6061 | 40 | >5.5 | 7 | 30*1 | 6*4 | 21 |
LHQD-48-6 | 48 | 6 | 686×686×50 | Aluminum 6061 | 40 | >10 | 7 | 30*1 | 6*6 | 21 |
