Quick Details

• Output Power:

  24w

• Output Voltage:

  12v

• Length:

  3cm

• Width:

  2cm

• Height:

  6cm

• Samples:

  Not Available

• Delivery Time:

  1 Working Day

• Packing:

  1 Stardard Package

• Export Ratio:

  81% - 90%

• OE Experience:

  No

Product Name:Launch Creader VI OBD2 OBDII Code Reader Launch X431 Master Scanner

Launch Creader VI OBD2 OBDII Code Reader Launch X431 Master Scanner

Application

Launch Creader

Product Description:

Detailed Product Description

Launch Creader VI OBD2 OBDII Code Reader

The Creader VI is the latest in Launchs line of professional code readers and scanners. Building upon the success of its predecessors, the Creader VI adds a new ergonomic design with a full color QVGA LCD screen and blazing fast speedfor better graphing and live data readings.
Launch Creader VI OBD2 OBDII EOBD Code Reader

Function:

Read dynamic datastream
MIL indicator
Readiness status test
Search freeze frame data
Read current DTCs
Clear DTCs
O2 sensor detection test
Specified monitoring system on-board monitor test
Read pending DTCs
Read on-board systems or components control
Read vehicle information
Read permanent DTCs
DTCs search
Tested data playback

Language: English

Specification:

Screen: 2.8'' TFT 262K true color, 320*240 Pixels LCD display
Input voltage range: 8 ~ 32V
Operating current: <100mA 12V(Typical)
Power consumption: <1.2W(Typical)
Link connection: Standard OBD 16-pin DLC
Operating temperature: 0 ~ 50
Storage temperature: -20 ~ 70 @ RH 60%
Outline dimension: L * W * H = 121 * 82 * 26mm
Weight: 500g per set

Package list:

1pc x Launch Creader vi
1pc x USB Cable
1pc x User manual
