Horizontal Balancing Machine For Vacuum Pump (PHQ-16A)

    • Application: Alfa romeo
    • Market Type:After Market
    • FOB Price: USD 1
    • Other Price Term: FOB
    • Payment Terms: L/C, T/T
    • Samples: Not Available
    • Minimum Order: 1Set/Sets

Quick Details

  • Samples:

    Not Available

  • Delivery Time:

    Within 7 Days

  • Packing:

    Pallet

  • Delivery Port:

    Shanghai

  • Max. Production Capacity:

    3000 Sets

  • Export Ratio:

    21% - 30%

  • OE Experience:

    No

Product Name:Horizontal Balancing Machine For Vacuum Pump (PHQ-16A)

Horizontal Balancing Machine For Vacuum Pump (PHQ-16A)

Application

Alfa romeo

Product Description:

Horizontal Balancing Machine for Vacuum Pump



Production Description



Specially designed brackets transmit mechanical force with low vibration damping
Durable and reliable sensor possesses good linearity
Permanent calibration brings high accuracy with a permission of large initial unbalance amount
Belt-driving offers higher precision and easier operation
Advanced electrical measuring system and friendly man-machine interface
Modular design offers a wide range of application



Range of Application



This balancing machine is widely used in balancing rotatable bodies, such as kinds of small-sized motors rotors, impeller, fans, crankshaft, turbocharger, water pump, roller, grinding wheel, main shaft of machine tool , textile machinery, tool , spindle, etc .. Driven by Nylon belt , equipped with Variable speed motor to drive .Which ensures high quality balancing and precision. quick booting ,easy operation. and high efficiency .



Special Features



The measuring unit employs JP-380 Micro- computer Electric Measuring Instrumentation newly developed by ourselves with piezoelectric transducer as electromechanical sensor. The measuring unit can show rotating speed, measured value, and phase position intuitively with options of six support modes available while the piezoelectrical sensor possesses a large capacity of output, small volume and high stability.


 Production Parameters


Technical data at a glance
PHQ-5A/16A
Max Mass of Workpiece (kg) 5/16
Max Diameter of Workpiece (mm) 300
Distance between Two Support Bearings (mm) 60-400
Journal Diameter Scope of Workpiece (mm) 5~40
Diameter Scope of Driving Belt (mm) 15~150
Rotation Speed when the Diameter of Driving Belt is 100mm (r/min) ~1470
Motor Power (kw) 0.23DC Stepless speed regulation
Min Achievable Residual Unbalance Amount (emar) 0.3g@ mm/kg
