The DAVIE XDc II communicates with the ECU's in the truck via the truck side "Diagnostic Connector" by using a special communication interface, called the Vehicle Communication Interface (VCI).
The VCI switches the input channel automatically to the required data line (K- line, L-line) or CAN-bus of the truckside "Diagnostic Connector".
The DAVIE XDc II provides two options for the communication between VCI and DAVIE XDc II, wireless or via cable (USB). Normally, the VCI communicates with the DAVIE XDc II by Wireless-LAN radio communication.
Features :
DAVIE XDc II can diagnose, troubleshoot and program following vehicles systems :
- CAB climate system
- Safety system
- Security system
- Transmission system
- CAB climate system
- Vehicle control system
- Door control system
- Instrumentation system
- Engine system
- Tachograph
- Communication system
- After treatment system
- Break system
VCI-550 specification:
Dimensions (W x D x H) 126 x 214 x47 mm
Power supply from the vehicle electrical system
The VCI must be powered from the vehicle.
Rated voltages 8 to 32 V DC.
Current consumption in the load range Max. 1 A
If external power is interrupted, the VCI will be
buffered by the rechargeable battery
Battery type NiMH 4,8V/1100mAh
Set includes:
- Blue VCI (1)
- VCI-USB Cable (1)
- Vehicle Diagnostic cables
- Carrying case (1)
Languages supported:English,Russia
Version: 5.5.0
