OEM No/Model: CTL023
Launch X431 Solo Diagnostic Equipment
X-431 Solo is a newly developed diagnostic equipment by launchwhich is not only a specialized diagnostic equipment, but also a universal diagnostic equipment. As inherited all the advantages from its cousin X-431 Diagun,X-431 Solo has the powerful diagnostic capabilities abundance of diagnostic software and stable test performance, etc. Besides, the integrated design of main unit and universal-16pin standard connector makes it become humanized, light and portable.
Features
1.Integrated design of main unit and universal-16pin standard connector
2.Users can select individual software accordingly
3.Universal 16 PIN connector, combined functions of all 16 PIN connectors
4.Covering a wide range of vehicle models
5.Fast upgrading via the Internet to keep up with the latest vehicle models
6.Perfect after-sale service system, customer can enjoy one-on-one considerate service all the life
Packing List
SeriaINo: |
||||
No. |
Part category |
Part No. |
Part name |
Quantity |
1 |
Main urnl |
201023880 |
X-431 SOLO host |
1 |
2 |
Connedor |
203010504 |
SMART OBDII-16E |
1 |
3 |
Test cablo |
Y203010229 |
MAIN CABLE |
1 |
4 |
Software memory card |
1204011021 |
TF Card |
1 |
5 |
Accessories |
10702DBS4 |
Privaie & confidential |
1 |
6 |
Accessories |
108040108 |
TF card reader |
1 |
7 |
Accessories |
107010925 |
X-431 SOLO Product Manual |
1 |
Connector list:
Toyota--17
Toyota--22
Mitsubishi/hyunbai 12+16
Nissan 14+16
Honda-3
Mazda-17
Kia-20
Benz-38
BMW-20
GM/VAZ-12
Ford6+1
Chrysler6
Universal 3
Fiat 3
Audi 4
Daewoo 12
Ssangyong14
Subaru 9
Benz 14
Ssangyong20
Diagun box connect cable
Lighter cable
Clipper cable
Tech Specs
CUP: 400MHz ARM9
Operating systemWin CE 5.0
4.3 inch high-brightness, high-resolution color LCD touch screen
Power supplyDC12V/ DC24V
1G memory card
X431 solo is similar with x431 diagun, difference between?
1. x431 solo haven't battery, it's used by power cable, it's better to use.
2. x431 solo haven't Bluetooth.
FAQ
X431 SOLO is a hi-tech product, which is the scientific and technological product of Launch. Nowadays, automotive technology are making daily advance, and there may be some questions during operation. Read the X-431 SOLO users manual carefully to get answers whenever you have any questions, or contact our Customer Service Center for help. Here list some frequently asked questions and answers relating to X-431 SOLO.
About Online Update
Q1: Downloaded diagnostic program package is not listed in the update tool,what is the reason?
A1: possible causes and solutions:
1.The downloaded diagnostic program and diagnostic update tool should be in the same folder. Please put them in the same folder.
2.The diagnostic update program may have not been fully downloaded.
Please download again.
Q2: When the updated software is used in vehicle diagnosis, some diagnostic program can not be downloaded successfully from the TF card. Why?
A2: possible causes and solutions:
1.The Display Program may have not been updated. Please update the Display Program.
2.The diagnostic program for the vehicle may be damaged. Please re-download the diagnostic program and update.
About Hardware
Q1: Why the LCD touch screen responds so slowly in cold weather?
A1: It is because the ambient temperature is close to the lower limit of operating temperature range (0-50°C). In this situation, it is necessary to warm up the machine for 30 minutes before test.
Q2: Why there is no character on the backlit screen?
A2: Check if the power is well connected. Turn off the machine, unplug the Power supply and then plug it, one second later, try to turn on the machine.
Q3:Why X431Diagun fails in communication with ECU?
A3: Please check and make sure that the diagnostic connector and diagnostic program are matching the vehicle make.
04: Why cant the data be input after Soft Keyboard is activated?
A4: The position where the cursor locates cant be edited. Or you have not activated the cursor in the input position, please use the stylus to click the part to edit. You can input the data if the cursor flashes.
Q5: Why the saved data disappeared?
A5: There are two possible causes:
1.YourTF card is damaged.
2.Youve changed la
