Quick Details

• Place of Origin:

  China

• Samples:

  Charge

• Sample Price:

  7600

• Delivery Time:

  Within 7 Working Days

• Export Ratio:

  81% - 90%

• OE Experience:

  No

Product Name:3D FOUR WHEEL ALIGNMENT Standard Model

3D FOUR WHEEL ALIGNMENT Standard Model

Application

any

Product Description:

MST 3D FOUR WHEEL ALIGNMENT
good quality with competitive price
one year warranty
quick delivery


Introduction:
3D measurement system consist of the PC, 3D camera and the targets, after digital
analysis
and calculation and get all the angles.

In 2008, we developed the first 3D wheel aligner in China and has been accepted by
market.
After the Standard model, we developed the Enhanced model which can measure
wheelbase
 and track width. In 2009, we developed the smart model which the camera can track all
 four
 targets automatically. In 2010, we developed the Extreme model which can measure the
 tire
diameter and caster trail.

3D-1	Dynamic measurement
3D-2	Track width, wheelbase, automatic compensation
3D-3	Auto-tracking camera system
3D-4	Intuitive measurement, rolling radius

Technical Advantages:
3D aligner no need the level ground and quickly get the measurement data in two
minutes;
except the normal angles, also can measure the Track Width, Wheelbase, Tire Diameter
 and
the Caster Trail etc.
1. On the basic of the Standard Model, automatic compensation without rolling the
 vehicle,
read the Toe, Camber, Set-back, Thrust angle and Track Width, wheelbase in 1 minute.
2. Dynamic Measurement: Complete the measurement in two minutes.
3. Easy to get the data of Track Width, Wheelbase and Intuitive Measurement.
4. Roll the vehicle in short distance and no need the lengthen lifter.
5. It is not necessary to perform calibration at the customer site.
6. Perfect products family.

Compare to the Past Sensors:
1. The targets without electronic components and easy to maintain.
2. The targets no need to charge, no need level and no influenced by the temperature.
3. No compensation and raise working efficiency.

pecifications & Features:

Specifications	Standard model 3d-1	Enhanced model 3d-2	Smart model 3d-3	Extreme model 3d-4
3D Cameras	v	v	v	v
Camera post	v	v
Automatic Tracking kits			v	v
Lenovo Computer	v	v	v	v
19 inch LCD Monitor	v	v	v	v
Printer	v	v	v	v
Connecting Box	v	v	v	v
Cable	v	v	v	v
Dynamic Measurement		v	v	v
Special Clamp ( optional)		v	v	v
Steering Wheel-Holder	v	v	v	v
Brake Pedal-depressor	v	v	v	v
Turntables	v	v	v	v
Cabinet	v	v	v	v
UPS			v	v
User manual	v	v	v	v
Features	Standard model 3d-1	Enhanced model 3d-2	Smart model 3d-3	Extreme model 3d-4
