Product  Name: GM Tech- 2 PRO Kit (CANdi & TIS)
Part No. : 108
Net  Weight: 5KG

The Tech- 2 is the same tester GM Technicians use to diagnose GM vehicles. The Vetronix Tech 2 comes with Authentic GM software and provides support for on- Board diagnostics on all GM systems 1992 thru 2008

Features:
Authentic GM software in the Tech 2 Flash means the most comprehensive diagnostic software available for late model GM vehicles.
Support for on- Board diagnostics on all GM systems 1992 thru current year.
Removable hardware modules provide insurance against scan tool obsolescence.
Large, Easy- To- Read backlit screen.
RS232 & RS485 ports provide the avenue to connect future devices to your Tech 2 Flash.
Ability to capture stored DTCs, Freeze Frame, And Failure Record for later review.
Ability to view the status of vehicle diagnostic tests as they run.
Bi- Directional
The authentic GM 1992- Current year software will provide full bi- Directional control when performing power train, Chassis, And body diagnostics.

Vetronix Tech- 2 Specifications
Dimensions
  12" X 6" X 2"
Microprocessor
  32 bit, 16 MHz
Memory
  32 MB flash type II PCMCIA. Type III slot available for future expansion.
Communications
  Integral RS232 communication port.
Screen
  3. 8" X 2. 8" Backlit monochrome with full graphics capability: 320 X 240 pixels. Displays up to 9 vehicle parameters at once
GM Tech- 2 Starter Kit with Candi Module & TIS Kit includes (All ORIGINAL and NEW!):

Tech- 2 Flash Tester
32 MB PCMCIA Card with GM OE Applications
CAN diagnostic interface module(CANdi) and instruction sheet download ( 199. 2 kb )
TIS2000 dongle to access SPS/ Security features
Data/ Sensor/ Trouble Code Manual
DLC Cable, DLC Loopback Adapter
12V Cigarette Lighter Power Cable
SAE 16/ 19 Adapter
NAO 12/ 19 Adapter
Battery Power Cable
Storage Case

An industry change in protocol from OBD II to Controller Area Network (CAN) has begun. In order to perform diagnostics on a vehicle that uses the CAN interface; You will need the Tech 2 Flash and a CAN diagnostic interface module. The module connects between the Tech 2 Flash's diagnostic link cable and the OBD adapter. Once the module is connected, It can be used on all GM vehicle applications, Even those vehicles using other platforms such as OBD I and OBD II.
