OEM No/Model: LHQD
Move Heavy Machinery & Equipment on Air are one of the most versatile pieces of air film equipment .
They are used in exactly the same way as conventional roller skates would be.
The Move Heavy Machinery & Equipment on Air are simply placed underneath the load to be moved,air is applied,and the load is simply pushed to the required position.
Move Heavy Machinery & Equipment on Air also called air caster, air powered moving casters, air bearing casters, air roller skates, air rollers, air moving skates, air powered heavy load moving equipment systems and so names.
Move Heavy Machinery & Equipment on Air LHQD ,a kind of pneumatic device which can form a lubricating film of air between the load and floor surface,used to move heavy equipment on flat, non-porous ground.
Move Heavy Machinery & Equipment on Air applicable scope:
Move Heavy Machinery & Equipment on Air LHQD handling equipment under clean environment [clean room, clean room dedicated]
Move Heavy Machinery & Equipment on Air LHQD features:
Move Heavy Machinery & Equipment on Air LHQD on the ground friction is small, can be well protected ground;
Move Heavy Machinery & Equipment on Air LHQD and maintenance simple, good safety performance;
Move Heavy Machinery & Equipment on Air LHQD can be shipped according to the weight and volume of objects in combination, for large and small weight of transport;
Move Heavy Machinery & Equipment on Air LHQD can be combined volume size, light weight, easy to carry or install;
Move Heavy Machinery & Equipment on Air LHQD can be used alone, without jack, hand destroyed the top of the tie.
Move Heavy Machinery & Equipment on Air Brand:LONGSHENG
Move Heavy Machinery & Equipment on Air Model:LHQD
Move Heavy Machinery & Equipment on Air Load:10-48T
Move Heavy Machinery & Equipment on Air Warranty:1 years
| Model | Capacity |
Quantity of Air Cushion |
Size of Air Cushion |
Main Material of Air Cushion |
Height of Air Cushion |
Main Gas Supply Flow |
Pressure |
Main Pipe Length |
Vice Pipe Length |
Net Weight of Each Air Cushion |
| (T) | (L×W×H,mm) | (mm) | (m3/ min) | (kg/cm2) | (m*quantity) | (m*quantity) | (kg) | |||
| LHQD-10-4 | 10 | 4 | 380×380×50 | Aluminum 6061 | 40 | >3 | 7 | 30*1 | 6*4 | 8.5 |
| LHQD-16-4 | 16 | 4 | 485×485×50 | Aluminum 6061 | 40 | >3.5 | 7 | 30*1 | 6*4 | 13 |
| LHQD-20-4 | 20 | 4 | 540×540×50 | Aluminum 6061 | 40 | >4 | 7 | 30*1 | 6*4 | 17.5 |
| LHQD-32-4 | 32 | 4 | 686×686×50 | Aluminum 6061 | 40 | >5.5 | 7 | 30*1 | 6*4 | 21 |
| LHQD-48-6 | 48 | 6 | 686×686×50 | Aluminum 6061 | 40 | >10 | 7 | 30*1 | 6*6 | 21 |
