Quick Details

• Size:

  73*47*21cm

• G.W:

  30kg

• Certification:

  ISO9001

• Color:

  Gray

• OIL TANK VOLUME:

  18L

• Place of Origin:

  CHINA

• Samples:

  Charge

• Sample Price:

  310

• Delivery Time:

  20 Days Since Receiving Advance Payment

• Packing:

  POLYWOOD PACKING

• Delivery Port:

  SHANGHAI

• Max. Production Capacity:

  6000 Per Month

• Export Ratio:

  31% - 40%

• OE Experience:

  No

Product Name:Hydraulic Oil Cooler For Concrete Mixer With High Heat Transfer 18L

Hydraulic Oil Cooler For Concrete Mixer With High Heat Transfer 18L

Application

SANY,XCMG,ZOOMLION

Product Description:

1.18L oil cooler for concrete mixer truck;
2. thermostatic control:50- 55 centidegree;
3. with 24V fan ;
4. oil filter grid: 10um ;

5.   6-10m³ drum size ,6 - 15 kW

6.with ISO9001/14000 certificate;


1. 18L concrete mixer truck cooler,plate oil cooler,aluminum plate fin heat exchanger

2.other option:15L,26L ;

3.thermostatic oil temperature control:50- 55 centigrade

4.oil inlet on the top of the tank

5.absolute aluminum plate heat exchanger

6.24V fan for concrete mixer truck cooler(option:12V)

7.switch makes sure the fan work intermittent

8.filter grid size is about 10um

another side of this cooler with the temperature switch

details of the fan

Accessories for the oil filter

 QUALITY CONTROL:

 Aluminum fins are the basic compollernts of plate-fin heat echanger,on which the heat transfer depends.there are many types of  fins.

such as :straight fin,perforated fin.offset fin,louvered fin and corrugated fin which can meets various requirements.

18L concrete mixer truck cooler,plate oil cooler,aluminum heat exchanger provided,if you are interested in this,or 15,26L oil cooler,please feel free to contact with me.

The factory specilize in desgin and manufacture heat exchangers(such as oil cooler,air cooler,water cooler) for construction machinery,air separation,pre-cooling and evaporation and air compressor.For more information,pls free to contact with us,thanks.
