Bulb size available: H1,H3,H3C,H4,HB2,9003,H4H,H4L,H4 HI/LO,H7,H7R,H8,H9,H10,H11,9008,H13 HI/LO,9004,HB1,9004 HI/LO,9005,HB3,9006,HB4,9007,HI/LO,880,881,D1 series,D2 series,D4 series
Color temperature: 3000K(gold yellow), 4300K, 5000K, 6000K, 8000K, 10000K, 12000K, Deep Blue ,Pink,Purple,Green
Item include:
1.Two 35W HID lamp;
2.Two 35W HID ballasts;
3.Installation accessories;
4.Installation manual;
5.Ralay hamess (fo H/L)
If you are interested in any of our products or have a customized order,please contact us now for further communication.
Electrical Parameters
Input Voltage Range:
8-18V DC or 8-32V DC
Operating Voltage:
13.2V DC Typical
Cool Starting Current:
<5.5A (13.2V DC In)
Hot Starting current:
<3.5A (13.2V DC In)
Input Current:
<3.2A (13.2V DC In )
Output Power:
35W± 1W Constant Power
Output Frequency:
380Hz-400Hz
Output Voltage:
70-180V AC True RMS Square Wave
Operating temperature:
-40degrees Celsius to +105degrees Celsius
Storage temperature:
-40degrees Celsius to +105degrees Celsius
Efficiency:
≥88%With Input 13.2V DC
End Of Life Lamp Voltage:
>180V AC RMS Square Wave
High Efficiency ,Low Power And High Reliability
IGNITOR
Trigger Output Voltage :
> 23KV
Trigger Intput Voltage :
380V AC
Protection
1.Output Open/Short Protection:Shutdown In 0.5 Sec
2.Over-Voltage ,Under -voltage Protection
3.Reversed Input Protection
Water Proof
1.HID Xenon Conversion Kit H3 5000K ,Xenon Lamp
2.Quality first,best price benefit,honest and trustworthy,service thorough
