Product Name:New Energy Charging Module Connector

New Energy Charging Module Connector

Application

power hot-swap terminal

Product Description:

New Energy Charging Module Connector
The module connector is also called the power hot-swap terminal and the cabinet connector, and is mainly used for the module power interface, the USB power interface, the server, the charging pile battery module and the like. The module connector contacts are made of high-strength, high-elasticity. The copper is used as the crown spring jack and the crown spring pin is gold-plated or silver-plated. The high dynamic contact is reliable. The plug is a crimping pin and the socket is a pin. Jack (can also be made into crimped form), with anti-blind insertion function, soft plugging and unplugging, small insertion and extraction force, low contact resistance, high load current and excellent electrical conductivity.

Module connector housing model:

Module connector process using connector requirements, methods and precautions:

Installation form

1,The screw locking method is adopted between the product and the printed board. It is recommended to see the opening dimensions of the printed board as detailed information on each page (without tolerance of ±0.2; unit: mm):

Requirements for use of the connector (after assembly to the component)

2,Shape tolerance requirements, fit speed, force, etc. for plugs and sockets. The connector mounted to the panel is mated with the panel in the subrack, and the overall structure of the subrack should meet the mating requirements of the connector. The speed with the socket is recommended to be no more than 12 times/min. When working, it must be fully inserted into place when connecting with the socket, and no additional device is allowed between the plug and socket mating faces to avoid affecting the contact reliability of the connector.

Xi'an spring technology Co., Ltd. is a professional push pull connector manufacturer integrating connector research and development, production and sales! We produce high-performance connectors independently, which can replace LEMO connectors, FISCHER connectors, ODU connectors. Of course, our ...[Read More]
