RG59 COAXIAL CABLE (200Mts)
in Close-Circuit Television(CCTV),Community Antenna Television(CATV) and direct broadcast satellit
RG59 COAXIAL CABLE (200Mts)
Combined Cable/CCTV Cable
This cable is designed to carry a high-frequency or broadband signal, as a high-frequency transmission line. Sometimes DC power cable is added to the signal to supply the equipment at the other end. Such as in Close-Circuit Television(CCTV),Community Antenna Television(CATV) and direct broadcast satellite receivers
1) Coaxial Cable with Other Cable
Coaxial Cable (RG 6, RG 59,MINI RG 59/RG 174) Combined With Power Cable
Coaxial Cable (RG 6, RG 59,MINI RG 59/RG 174) Combined with Power cable and Data Cable
Specification :
l Conductor: 1/0.643 Copper
l Dielectric: 3.7mm,Solid PE
l Shield: Aluminum Foil
l Braid: Bare Copper, 95% braid coverage.
l Sheath: PVC (Polyvinyl Chloride)
l Overall Diameter(mm±0.1): 6.0mm
l Sheath Color: Black, White, Any Color
l Package: 100 Mtr’s ,300 M tr’s and 500 Mtr’s per spool.
Options: Any braid coverage, any material of copper and sheath are available.
2) Characteristics
Impedance: 75 Ohm
Capacitance (pF/M):67
Velocity of Propagation(%):66
Temperature Range: -20+80°CApplicable scope: high building dialog series, monitoring, closed circuit monitoring and wired television engineering and video teaching meeting engineering Package: cartoon, wooden drum, plastic drum Special cables can be made according to your requirement. Welcome to negotiate OEM with us
Attenuation[@68°F. (20°C)]
Frequency(MHz)
Maximum(dB/100ft)
Maximum(dB/100m)
5
0.58
1.90
55
1.60
5.25
83
1.95
6.40
187
2.83
9.30
211
3.05
10.00
250
3.30
10.82
300
3.55
11.64
350
3.85
12.63
400
4.15
13.61
450
4.40
14.43
500
4.66
15.09
550
4.90
16.08
600
5.10
16.73
750
5.65
18.54
865
6.10
20.01
1000
6.55
21.49
Main Export Markets:Mid East/Africa Central/South America Australasia Europe
Payment Details:
Payment Terms:L/C, T/T at sight
Minimum Order:5,000M
Delivery Details:
FOB Port:Shenzhen
