Quick Details

Product Name:Vacuum Machine Oil Purifier Used Oil Purifier Filtration Equipment Oil Refining Machine Lubricant Oil Recycling Machine

Vacuum Machine Oil Purifier Used Oil Purifier Filtration Equipment Oil Refining Machine Lubricant Oil Recycling Machine

Application

nakin NAKIN Oil Purifiers / Oil filtration machine / oil recycling / oil refinery / energy / recycling equipment / power products / environment / machine manufacture / supplier NAKIN machine can purify unqualified lubricating oil, mechanical oil, hydraulic oil, compressor oil, turbine oil, refrigerator oil, No. 10, No. 25 No. 45 transformer oil, mutual inductor oil, cable oil, switch oil, used cooking oil, waste black engine oil, transformer oil and so on . NAKIN products are widely applied in projects of transformer substation, electric department,steel structure, bridge, auto, railway, aviation, chemicals, petroleum etc. The products are exported to more than 30 countries and areas, such as Europe, America, Middle East, Southeast Asia and so on. Each product of NAKIN is professionally tested, and the machine quality and oil quality are guaranteed. It has achieved a good reputation in the hearts of dealers and end users. Tel/Whatsapp +86 13554190393 Email: nakinoilpurifier66@hotmil.com Company website:

Product Description:

OEM No/Model: TYA300
  Tel/Whatsapp +86 13554190393
Company website:
TYA Lubricating Oil Purifier
Application:
TYA Vacuum lubricating oil purifier mainly deals with unqualified mechanical oil, hydraulic oil, compressor oil, turbine oil, refrigerator oil etc. It can quickly and effectively remove water, gas, impurities and volatiles (such as alcohol, gasoline, ammonia, etc.) from oil. it restores oil viscosity, flash point and other performance indicators. The filtered oil is low emulsification value, low water content, high cleanliness, which can be used again and again in high-precision hydraulic lubrication equipment. TYA Oil Purifier is suitable for various kinds of lubrication purification and regeneration treatment in petroleum, chemical, mining, metallurgy, power, transportation, machinery manufacturing, railway and other industries.

Features:
 The water separator uses high-molecular coalescing material as filtering medium, which integrates emulsification, dehydration and impurity removal.
 Strong ability to remove impurities: ultra-large area cylindrical precision filter element, with high filtration accuracy, easy installation and replacement.
 High-efficiency vacuum dehydration and degassing: Duplex-Stereo film evaporation technology
 Excellent heating system: carbon fiber electric heater with long service life, low heating surface load, linear temperature rise, preventing oil cracking, keeping oil uniform heating.
 Automatic control to realize unattended, safe and stable working.
 Safety interlock protection: oil pump, vacuum pump, heater interlock protection
 Humanized instructions: automatic design, and there are instructions such as oil temperature gauge, pressure gauge, vacuum gauge, filter pollution alarm, operating status and so on.
 This machine has the advantages of low noise, easy operation, long maintenance interval, low energy consumption, low operating cost, high oil filtration efficiency, long lifetime, etc.



Optional Device:
A- Optional PLC control.
B- Oil pump set, vacuum pump set, filter element and electrical parts are selected imported brand products.
C- Flow meter, online moisture monitoring
D- Select the appropriate explosion-proof level according to the working environment (ExdII BT4 / ExdII CT4)

Technical Parameters:

Index		Unit	TYA-10	TYA-20	TYA-30	TYA-50	TYA-100	TYA-150	TYA-200	TYA-300
Flow rate		L/H	600	1200	1800	3000	6000	9000	12000	18000
Working vacuum		MPa	-0.06-0.095
Working Pressure		MPa	0.4
Working Temperature			20 80
Power Supply			380V 50HZ,3Ph (or According to user demand)
Working Noise		dB(A)	6580
Heating Power		Kw	24	24	24	30	48	72	96	120
Total Power		Kw	27	27	27	33	53	78	102	128.5
Inlet / Outlet		mm	25	25	25	32	40	50	50	65
Weight		kgs	450	480	500	550	650	800	1000	1300
Dimension	L	mm	1550	1550	1550	1650	1750	1800	1900	2100
	W	mm	1100	1100	1100	1200	1250	1500	1600	1800
	H	mm	1650	1650	1650	1750	1750	1850	1950	1950
After Purification
Demulsification value		min	15/min(GB/F7035)
Water Content		ppm	80
Gas Content		%	0.1
