Filtermat is made of such synthesized fibers as polyester, Polyamiade and nylon, Which is characterized with high- Air- Permeability, Low pressure drop and large dust- Holding capacity.
Features:
Patented anti- Broken, Closely- Bonded synthetic fibers, No shedding;
No use of chemical binder, Thermal- Bonded techniques, Retardant to fire;
Humility- Resistant up to 100%R. H. ;
Heat- Resistant up to 100 Celsius Degree;
Washable type available;
Imported type with progressive structure i. E. Progressive increase of fiber density toward downstream side which effectively extends lifetime.
Technique parameter (EN779)
| Title | Filter class | Average efficiency(%) | Initial pressure(1. 5m/ S) | Flammability class | Dimension(m/ Roll) | Thickness (mm) | Remark |
| KG- 200/ 12W | G3 | 83 | 25Pa | 2X20 | 12 | ||
| KG- 250/ 15W | G3 | 85 | 30Pa | 2X20 | 15 | ||
| KG- 300/ 20 | G4 | 92 | 38Pa | 2X20 | 20 | ||
| KG- NGB290/ 4 | G4 | 92 | 38Pa | F1 | 2X20 | 20 | |
| KG- 300NF/ 1 | F5 | 97 | 60Pa | F1 | 2X20 | 20 | |
| KG- 300/ 20RW | G4 | 90 | 33Pa | F1 | 2X20 | 20 | |
| KG- 200/ 20T | G4 | 90 | 49Pa | F1 | 2X20 | 20 |
Note: 1. Special dimension based on customer's requirements available |
