Product Name:Rear Drive System Training Bench

Rear Drive System Training Bench

Application

BMW

Product Description:

Automotive Rear Drive System Trainer





Functional Characteristics:

1The equipment is made up of the original rear-drive drivetrain components of the Gold Cup Sea Lion, including: manual transmission, clutch, drive half-shaft shaft, swingarm, rear drum brake assembly and other rear-drive drivetrain components in normal operation. A visual representation of the structural composition and working principle of the rear-drive drivetrain.



2YM112 1.3KW three-phase motor drives the reducer, the reducer drives the transmission input shaft for low-speed operation, realistic simulation of the transmission system power transfer process. It is suitable for the needs of secondary and higher vocational and technical colleges and automotive training institutions in teaching students about automotive drivetrain systems.



3With clutch pedal and shift lever, it can dynamically demonstrate the working status of each transmission gear under different transmission ratio conditions, which is convenient for teaching and easy for students to understand.



4With transmission drive half-shaft and rear drum brake assembly, the frame can show the structural composition of the front drive system to facilitate students' understanding.



5Independent suspension mechanism, transmission, half-shaft, brake and other parts are complete, reliable and effective operation. It can carry out practical training on the dismantling, installation, commissioning and verification of the variable speed system, transmission system and brake system.



Overall Shape:



1. The rear wheel drive transmission system equipment is based on the fixed style of the original transmission, the overall design of the vertical mechanism, the equipment structure is stable, new style, beautiful and high safety factor.





2. The frame is made of 40*40mm; 70*40mm and 5 thick high quality steel pipe, which is specially welded for durability.



3. Wheel structure: radius: 50mm thick universal nylon wheel with locking nylon wheel device, which can be fixed/row mobile teaching.



Major Dispositions:

Manual gearbox 1.

Clutch 1.

1 drive half shaft.

2 sets of swing arms.

2 sets of front disc brake assembly

YM112 1.3KW three-phase asynchronous motor 1

60:1 reducer 1.

1 removable stand.

40*40mm square iron 10 M

70*40mm square iron 10 M

1 copy of the instruction manual for use.



Echnical Parameters:

1Input power: single phase ~ 220V±10% 50Hz

2Weight: 40±10kg

3Working temperature: -4050

4Exterior dimensions: (L*W*H): 3000*1000*1100(mm)
