Product Name:11 Great Wall 2.8TC Diesel Engine Disassembly Operation Training Platform

11 Great Wall 2.8TC Diesel Engine Disassembly Operation Training Platform

Application

Changan

Product Description:

Great Wall 2.8TC diesel engine disassembly and operation training platform
1. Product introductionThe training bench is composed of two parts: the disassembly and assembly turning bench of the Great Wall 2.8TC diesel engine assembly (easy to disassemble and assemble) and the operation inspection console. The disassembly and assembly turning stand provides trainees with engine disassembly and assembly training. After the engine is assembled, it can be connected to the operation inspection console, and the engine can be started and operated to test the assembly effect of the engine.two. Features1. The color inkjet circuit diagram is drawn on the panel of the training platform. Students can intuitively compare the circuit diagram and the real object of the electronically controlled diesel engine to understand and analyze the working principle of the control system;2. The training platform consists of two parts: the disassembly and assembly of the overturning platform and the operation and detection console.The disassembly and reversing bench is composed of an electronically controlled diesel engine assembly and an engine disassembly and assembly frame that can be turned 360 degrees. The operation inspection console is composed of a control panel, an engine electronic control unit, a cooling system, an oil supply system, and a battery;3. The disassembly and reversing stand with the reducer can be turned over and stationary at any axial angle, and can be easily disassembled and assembled for training. An oil tray is placed at the bottom to facilitate the collection of small parts, water and oil. to three do not land;The operation inspection console frame is equipped with all the components for starting and running the engine, such as electronic control unit, water tank, oil tank and oil pump, instrumentation, ignition switch, etc. , can run the engine (acceleration/deceleration/idle conditions are normal), and check the effect of engine assembly;4. The color UV flat-panel inkjet circuit diagram is drawn on the panel of the training platform. Students can intuitively compare the circuit diagram and the actual engine to understand and analyze the working principle of the control system;5. The panel is made of 4mm-thick high-grade aluminum-plastic panel that is corrosion-resistant, impact-resistant, pollution-resistant, fire-resistant, and moisture-proof. The surface is treated with a special process of spraying primer; the panel is printed with a color system circuit diagram that never fades. Installed with detection terminals, which can directly detect the electrical signals of each sensor, actuator, and engine control unit pins on the panel, such as resistance, voltage, current, frequency signals, etc.;There are automobile instruments, fuel pressure gauges, and vacuum pressure gauges installed on the training platform panel, which can display the changes of parameters such as engine speed, fuel injection pressure, and intake manifold pressure in real time;6. The training bench is equipped with a diagnostic seat, which can be connected to a dedicated or general-purpose car decoder to perform self-diagnosis functions such as reading fault codes, clearing fault codes, and reading data streams for the engine electronic control system.7. The training platform is equipped with installation protection devices such as the main power switch and the flywheel protective cover.8. The base of the training platform is welded by steel structure, and the surface is treated by spraying process.9. 10. Comes with disassembly, construction experiment outline, online teaching and operation video, and experiment instruction book; all equipment and its accessories, tools, and operation interface are all displayed in Chinese, all equipment is equipped with dust cover, and three years are provided after all equipment is qualified. For equipment warranty, it is necessary to complete the installation, debugging, demonstration, software installation, etc. of a complete set of testing platforms to ensure subsequent maintenance and updating of all software and hardware.three. Technical SpecificationsWorking power: DC 12VFuel label: 92#Fuel tank volume: 10L4. Supporting special tools, testing instruments, tool cabinets, workbenches2 tool carts;2 parts trolleys;2 sets of disassembly tools include: 8-piece cap filter wrench; professional-grade adjustable torque wrench; 2-jaw puller; 3-jaw puller; 120-piece vehicle maintenance comprehensive set; valve oil seal pliers; ; Diagonal nose pliers; Wire pliers; round mouth with bladed pliers; sharp nose with bladed pliers; wooden handle installation hammer.2 diesel cylinder pressure gauges;2 fuel pressure gauges;2 cooling system testers;2 diesel fuel injection timing testers;2 diesel engine tachometers;2 infrared thermometers;2 oscilloscopes for automobiles;2 diesel engine diagnostic instruments;2 diesel smoke meters;2 sets of high pressure common rail injector testers;2 sets of high-voltage electronically controlled pump testers.

Guangdong Zhongcai Education Equipment Co., Ltd. We are a manufacturer of automobile training equipments for use in vocational or technical institution. Located in Baiyun district Guangdong province China. With ISO9001, ISO14001 and CE certificate.More detail contact us freely[Read More]
