Quick Details

• Model:

  HONDA - GX160

• G.W:

  64kg

• The Maximum Power Speed:

  3600rpm

• Place of Origin:

  China

• Samples:

  Not Available

• Delivery Time:

  5-10 Days After Your Payment

• Packing:

  Carton Box, Plastic Bags, Wooden Cases Or As Your Requirement

• Delivery Port:

  Qingdao,Ningbo,Shanghai,Shenzhen

• Max. Production Capacity:

  1000sets

• OE Experience:

  No

Product Name:NCM - 4 Type Internal Combustion Switch Railway Grinder

NCM - 4 Type Internal Combustion Switch Railway Grinder

Application

china coal

Product Description:

chinacoal12
m.chinacoalintl.com NCM - 4 type Internal Combustion  Switch Railway  Grinder Keyword:railway grinder,internal combustion grinder,rails grinder
Feature:
1.Gasoline driven, strong adaptability to an open working environment.
2.The feeding of the grinding controlled by the electric, high polishing precision.
3.Following copying, easy operation.

Applicable scope
NCM - 4 type internal combustion switch grinding machine is mainly used for grinding switch switch of tongue rail, frog heart rail, wing rail top surface and side fat side, also can burnish all kinds rail top surface and side fat edge. Superior performance, reasonable structure, reliable quality, saves time and effort, is works departments maintenance line the necessary tools.

The main technical parameters
1, gasoline engine
Type: HONDA - GX160
Power: 3.05 kW
Speed: 3600 r/min
2, general flat grinding wheel
Specification:   250 x 32 32
Maximum grinding linear speed: 40 m/s
3, grinding vertical stroke: 170 mm
4, grinding wheel position adjust the Angle (from the vertical direction up to two side Angle respectively) : 30
5, outer profile size: 2900 x 850 x 1000
6, the machine quality: 114 kg

Shandong China Coal Industrial&Mining Supplies Group Co.,Ltd (hereinafter referred to as china coal) is a group company, which is a collection of e-commerce, machinery manufacturing, software, research and development, modern logistics of large diversified industrial group. The group has 100 ...[Read More]
