Quick Details

• Place of Origin:

  Jiangsu, China (Mainland)

• Delivery Time:

  0

• Packing:

  Wooden Package

• Delivery Port:

  shanghai port

• OE Experience:

  No

Product Name:12-cylinder diesel engine

12-cylinder diesel engine

Application

Universal

Product Description:

1.WANDI Series 12-cylinder engine : WD269TAD43
2.Rated power 432kw/1500rpm
3.Water Cooling
4.4strokes

(engine model)WD269TAD43standby (KW)475Rating (KW)432Cylinder bore×piston stroke(mm)138*150Number of cylinders12-cylinder V-typedisplacement(L)26.9Compression ratio14.7Intake modeTurbo air-cooledMaximum inlet resistance(kPa)6.2Air combustion(m3/h)3400Maximum exhaust back pressure(kPa)6Exhaust Flow(m3/h)

5700

 Exhaust gas temperature(*C)600CoolingRadiator

Fan exhaust flow(m3/h)

 52000The total capacity of the cooling fluid(l)135135The maximum water temperature(*C)95Thermostat thermostat range(*C)7284The maximum oil temperature(*C)100The total capacity of lubricating oil(l) Average fuel consumption(l/h)213Speed modeMechanical / electricalBattery capacity(AH)2X195AH  12V

Wuxi Power Engineering Joint-stock Co., Ltd., founded in 1956, is a large-scale company specialized in developing and manufacturing multi-cylinder diesel engines and their parts. Its brand "WanDi" ("WD") is one of the famous in the field in domestic market.

The ...[Read More]

Company Profile:

• Main Product:

  diesel engine,Boat diesel engine,marine diesel engine,genset diesel engine,fire water pump diesel engine

• Business Type:

  Manufacturer

• Current Export Market:

  South America, Eastern Europe, Southeast Asia, Africa
