Quick Details

• Current:

  25A

• Place of Origin:

  China

• Samples:

  Free

• Delivery Time:

  2 Weeks

• Packing:

  Bulk And Box Packing

• Delivery Port:

  Shanghai

• Export Ratio:

  71% - 80%

• OE Experience:

  No

Product Name:WEET Strong Item Electric Stoves Rectifier Bridge 1000V 25A GBJ2510 Flat And Thin Bridge Rectifier

WEET Strong Item Electric Stoves Rectifier Bridge 1000V 25A GBJ2510 Flat And Thin Bridge Rectifier

Application

Honda, Huandai, Huizhong, Hummer, Infiniti, Jaguar, Jeep

Product Description:

WEE Technology Company Limited

Manufacturer of Surface Mount (SMD) and Through Hole (DIP) Diodes & Rectifiers

WEET Strong Item Electric Stoves Rectifier Bridge 1000V  25A GBJ2510 Flat and Thin Bridge Rectifier

Model: GBJ2510, Brand: WEET, Package: GJB

Electrical parameters: 25A 1000V

Chip material: GPP

Forward current (IO): 25A

Number of chips: 4

Forward voltage (VF): 1.1V

Chip size: 140 mil

Surge current IFSM: 400A

Leakage current (IR): 5ua

Working temperature: - 55 ~ + 150

Recovery time (TRR): 500ns

Number of leads: 4

GBJ2510 is applied to products in the field of small current: small power switching power supply, power adapter,

LED light rectifier, electric fan, TV, indoor air conditioner, household appliances and other related electrical products.

Green laser printer laser marking, non fading,

Solve the problem of easy fading in ink screen printing

Laser marking has high production efficiency and short order period,

Solve the problem of long delivery time and low efficiency of ink printing

Advanced plastic packaging

One time injection molding with epoxy resin

Good fire resistance, high strength and high temperature resistance


Oxygen free copper pins

Oxygen free copper material, good conductivity

pin thickness upgrade up to 0.71mm,

Keep working for a long time without heating


Original "WEET" brand logo meaning

WEE = WEE Company name

T = Technology


How to understand WEET part number,  please see below Product analysis:

[GBJ2510] represents the complete model of the product

[GBJ] is the packaging method of the product

The number [25] indicates that the forward current is 25A

The suffix [10] indicates that the reverse withstand voltage is 1000V



WEE Technology Company Limited is a marketing office established in Hong Kong since 2000. We are specialized in manufacturing diodes and bridge rectifiers, both in surface mount and through hole Type, which including Zener Diodes,Switching Diodes,Bridge Rectifiers,General Rectifier Diodes,Fast ...[Read More]

Company Profile:

• Main Product:

  Diodes, Rectifiers, Bridge Rectifiers

• Business Type:

  Manufacturer

• Current Export Market:

  North America, South America, Western Europe, Eastern Europe, Eastern Asia, Southeast Asia, Mid East, Africa

Factory Profile:

• Number of Employees:

  401 - 500 People
