Glsun Mini Type 1x2 Fiber Optic Switch

Contact Supplier no sign-up required

Product Details

Company Profile

OEM No/Model: SUN-FSW-M1x2
Product Description Mini type 1x2 Fiber Optic Switch Features

·Low Insertion Loss
·Wide Wavelength Range
·Low Crosstalk
·High Stability, High Reliability
·Epoxy-free on Optical Path
·Latching and Non-latching

Application

·R&D in Laboratory
·System Monitoring
·OADM
·MAN (Metropolitan Area Network)

Detailed Images Specification

Mini type 1x2 Fiber Optic Switch - Specification
Parameters	Unit	M1×2 or M2×2 or M2×2B	M1×2 or M2×2B
Wavelength Range	nm	850±40 / 1300±40	1260 ~ 1650
Test Wavelength	nm	850 / 1300	1310 / 1550
Insertion Loss 1, 2	dB	Typ: 0.6 Max:0.8
Return Loss 1, 2	dB	MM ≥ 30 SM ≥ 50
Crosstalk 1	dB	MM ≥ 35 SM ≥ 55
PDL	dB	≤0.05
WDL	dB	≤0.3
Repeatability	dB	≤±0.02
Operating Voltage	V	5
Durability	Cycles	≥ 10 Million
Voltage Pulse Width (Latching)	ms	≥ 20
Switching Time	ms	≤8
Optical Power	mW	≤500
Operating Temperature		-5 ~ +70
Storage Temperature		-40 ~ +85
Relative Humidity	%	5 ~ 95
Dimension	mm	(L)21.0×(W)9.0×(H)12.0 ± 0.2
Note: 1 Within operating temperature and SOP. 2 Excluding Connectors.
