Automatic Mains Failure
Graphic remote display
Configurable inputs / outputs
Genset and mains protections
Full communication ports :
RS232/RS485 Modbus/CAN J1939
A BASIC UNIT WITH ADVANCED FEATURES
The TCGEN 2.0 monitors mains phase voltages and controls the automatic
starting, stopping and load transfer of the generating set in case of a mains
failure. All mains parameters are monitored and, in case of failure, the controller
will immediately start the generator.
When the voltage is within the programmed limits, genset contactor is immediately
closed on load.
During the running period, the engine and the alternator are monitored. Any
failure is shown on the display and will shut down the engine. When mains
reappears the controller will open the genset contactor and transfer the load
to the mains. The generator will be stopped after the cooling down time.
FEATURES
Engine speed measurement with magnetic pick-up / Alternator voltage
Back-lit LCD graphic display with multipages information
User friendly: a button per command and per LED indicator
and intuitive fluorescent keyboard
Help button for on-board instructions
Different password access
Configurable alarms and protections (57)
High accuracy TRMS measurement
Date and time (real time clock with battery)
5 languages available on board (English, French, Italian, Spanish, Russian)
Engine history events log (250) and data- logger
System statistics: engine, alternator and mains
Modem communication via GSM GPRS
Fast and easy setup
Fully programmable by keyboard
Modbus communication
Start engine depending of the mains load
