Quick Details

• Place of Origin:

  China

• OE Experience:

  No

Product Name:Micro Dc Hot Water Pump DC50

Micro Dc Hot Water Pump DC50

Application

GMC

Product Description:

Life for 10 years, maintenance-free; small size with high efficiency, low consumption,low noise,100% water-proof


Dimension and pictures

Specification

• voltage: 4.5V~24V DC(Standard 12V DC)
• Max flow: 2600L/H(43L/Min)or 12gallon/Min
• Max head: 7M
• Materials: ABS+PC or PA66
• Max bearing pressure: 0.7 Bar
• Max temperature: 70°C or 100°C
• Waterproof level: IP68
• Weight: 350g

Features

• Life-span for 10 years, maintenance-free; Small size but high efficiency, low consumption
• There is a sleeve in the middle of rotor and the rotor was fixed in the shell by high-performance ceramic shaft. the stator and circuit board are sealed by epoxy resin which are completely isolated with rotor.in this way the pump is completely water- froof.
• There are many parameters we can adjust at the same voltage, such as 24v pump's head can reach 2m, 7m is also possible. pump can work at wide range voltage: The 24V pump can run below 24v(4.5V to 24v).
• Three-phase without hall driver pump can adjust the head and flow by PWM, analog signals(DC0V to 5v) or potentiometer. Rotor-Lock and reverse connection protection is the biggest advantage
• Three-phase without hall driver pump can also work continuously in boiling water(212F)
• The long-term wear of pumps and large gap (which will have big noise)generated by the heating or cooling in long-term use of hot water were solved by the co-operation of high-precision ceramic shaft and sleeve, the noise can less than 35db(even in hot water), especially lower power pumps can reach 30db, nealy mute.
• Multi-functional design: Submersible or outside install (below the liquid surface)
• Can be customized according to user's requirements.

Notes





Three phase pump(100 degree,program controlled,speed adjustable:PWM,0-5V analog signal,manual adjustment )

Head-Flow Curve Graph
