Quick Details

• Place of Origin:

  Zhejiang, China (Mainland)

• Packing:

  Inter Packing : FoamOuter Packing:Carton

• Delivery Port:

  Ningbo or Shanghai

• OE Experience:

  No

Product Name:JQX-40F(JQX-52F) relay

JQX-40F(JQX-52F) relay

Application

auto

Product Description:

POWER RELAY WITH COVER,UP TO 40A

Features:
1) Outline dimensions: 74.0 x 47.0 x 47.0mm
2) Contact data:
a) Contact arrangement: 1Z(1C,1H)
b) Materials: silver alloy
3) Max. switching current: 40A
4) Max. switching voltage: 28V DC / 250V AC
5) Max. switching power: 1.12KW / 10kVA
6) Rated load (resistive): 1Z:28VDC/40A 250VAC/40A
                           2Z:28VDC/40A 250VAC/40A
7) Coil data:
a) Nominal voltage: 6 - 220V DC / 6 - 380V AC
b) Picd-up voltage: AC≤75%, DC≤90%
c) Drop-out voltage: DC≥10%, AC≥30%
d) Coil power: 3.5W / 5.5VA
8) Specifications data:
a) Contact resistance: ≤50mΩ
b) Insulation resistance: ≥500mΩ
c) Dielectric strength Vr.m.s:
i) Between open contacts: ≥1,500V AC
ii) Between coil and contacts: ≥2,000V AC
iii) Between contacts form: ≥2,000V AC
d) Ambient temperature: -45 - +55°C
e) Operation/release time: ≤20/20ms

Yueqing Qianji Relay Co., Ltd. is a modern enterprise that specializes in researching, developing, manufacturing and selling relay products.

We mainly manufacture all types of small relays, large power relays, automobile relays, timing relays, solid relays, counters, ...[Read More]

Company Profile:

• Main Product:

  All types of small relays,large power relays,magnetic latching relays,automobile relays,timing relays,solid relays,counters,temperature controllers,relay sockets,and switches

• Business Type:

  Manufacturer

• Current Export Market:

  North America, South America, Eastern Europe, Southeast Asia
