Quick Details

• Place of Origin:

  Zhejiang, China (Mainland)

• Delivery Time:

  0

• Packing:

  4PCS/Small Carton, 80PCS/Big Carton(External Packing),Dimension:51.5*24*34,G.W 29kG,N.W 27kG

• Delivery Port:

  Ningbo/Shanghai

• OE Experience:

  No

Product Name:Miniature Circuit Breaker(YDX-1P)

Miniature Circuit Breaker(YDX-1P)

Application

auto

Product Description:

Mini circuit breaker, mcb, miniature circuit breaker,circuit breaker, breaker

Apptication

YDX mini circuit breaker is mainly suitable for overload and short circuit protection,It is
especially used for illumination and distribution in industry and commerce.etc.It hasp leasing
outlook &high breaking capacity,reliable performance.high inflammable resistance and shock resistance for long service life.It is within the circuit of AC 50Hz/60Hz,rated voltage of single
pole up to 240V,two,three or four poles up to 415V,It can also be used for an unfrequent switchover of the circuit and illumination under normal condition. Main Technical DataStandardIEC60898,BS3781-1Number of poles1P.2PRated current(In)1,2,3,4,6,10,16,20,25,32,40,50,63Rated voltage(Un)AC240/415VRated frequency50/60HzTripping curveB,C,DRelease action characteristicsTime delay1.13In≥1h non-trip1.45In<1h trip2.55In 1S<60S tripInstantaneous(Curve C)5In≥0.1S non-trip10In<0.1 tripMagnetic releases operateB curve:between 3 and 5InC curve:between 5 and 10InD curve:between 10 and 14InRated breaking capacity(Lcn)3000A,4500A,6000AEndurance≥2500Circumstance temperature-5+40Electrical life≥6000timesMechanical life20000 timesTropical rationTreatmen 2(RH95%,at 55)Protection degreeIP20

It hasp leasing outlook &high breaking capacity,reliable performance and high inflammable resistance.

Wenzhou Yuanda Electrical Equipment Co., Ltd. was established in 1993. It is a joint venture company and an integral whole by manufacture, marketing and scientific research. It covers more than 15,000 square meters, has employees about 500.
After more than ten years vigorous ...[Read More]

Company Profile:

• Main Product:

  Circuit breakers,AC contactors,magnetic starters,Voltage stabilizers,Voltage regulator,power supply,Automatic voltage regulator,Mini Circuit Breaker,Earth leakage circuit breaker,molded case circuit breaker,relay,Magnetic,MOTOR CONTROLLERS,distribution box,AC voltage regulator,MCB,SVC,MCCB,RCCB,RCBO

• Business Type:

  Manufacturer

• Current Export Market:

  North America, South America, Eastern Europe
