LiFePO4 Battery 24V 200AH, lithium ion battery for vehicles

Application: Electric vehicles
Market Type:After Market
Price: US $3,000 - 5,000
Payment Terms: L/C, D/A, T/T, D/P, Western Union,MoneyGram,PAYPAL
Minimum Order: 1 Set

Contact Supplier no sign-up required

Add to Favorites

Product Details

Company Profile

Quick Details

Type:
Lithium battery
Capacity:
> 150AH
Voltage:
12X2=24V
Size:
520*320*246mm by 4pcs 260x158x246
Place of Origin:
Guangdong China (Mainland)
Brand Name:
O'CELL
Model Number:
24V240AH
Warranty:
2 Years
Material:
LiFePO4
Battery cell:
18650 or 26650
Color:
Blue
Case:
ABS IP56
Structure:
2S2P by 12V120AH module
email:
sales11 AT ocelltech.com
Place of Origin:
Guangdong China (Mainland)
Delivery Time:
within 20days
Packing:
standard export package for lithium ion batteries
Delivery Port:
SHENZHEN, HK
OE Experience:
No

Product Name:LiFePO4 Battery 24V 200AH, lithium ion battery for vehicles

LiFePO4 Battery 24V 200AH, lithium ion battery for vehicles

Application

Electric vehicles

Product Description:

LIthium battery, Lithium ion battery packs.LiFePO4 cells

Module Voltage:12V
Module Capacity:100Ah 2S2P to reach 24V200AH
2000 cycle life
Used for solar power storage

Advantage of our module:

Water-resistant and firm ABS plastic casing.
Built-in PCB protection.
Prevent short circuit, over-current, over-heat, over-charge, over-discharge.
The internal pack is stabilized by braces
Avoiding mechanical accidents caused by vibration

Specification:

Detailed Product Description
High drain up to 150A(30S);
Humanized monitor interface available;
Easy to install, expand,control and maintenance;

BMS:

OCELL BMS consists of Master BMS Circuitry (we named “BMU”), Slave BMS Circuitry (we integrate it into our battery module) and contactor.

Besides the basic functions such as over charge/ discharge, over current, short circuit, over temperature and balancing, Our BMS owns the following features

1. Master-Slave architecture makes the system flexible;

2. Two level warning makes maintenance easier;

3. CAN2.0 and industrial level electronic components make system reliable;

4. Contactor makes high rate charge & discharge feasible;

5. Periodic insulation measurement makes personnel safety possible;

6. Host can control the system easily;

Battery module:

1. Modular design makes the system installation, maintenance easier;

2. Battery modules can be connected in series or parallel to make the system more flexible;

3. IP56 dust and water proof design suit for in severe circumstance;

4. Dual LED indicator makes the battery module status easy to know;

5. High accuracy SOC calculation;

No.	Item	Specification
1	Battery module	IFM12-1200E1(12.8V120Ah)
2	Assemble method	IFR26650
3	Nominal capacity/Ah	120Ah
4	Nominal voltage/V	25.6V(12.8V*2)
5	Max. Charge voltage/V	≤28.4V(14.6V*2)
6	Discharge cut-off voltage/V	≥20.0V(10.0V*2)
7	Recommended charge current/A	≤55A
8	Discharge current/A	≤155A
9	Max. discharge current/A	≤300A(10S)
10	Weight/Kg	<56Kg
11	Approximate resistance/mΩ	<60mΩ
12	Dimension(for reference only)	depend on configuration
13	Temperature range	charge:0~45°C
13	Temperature range	discharge:-10~50°C
14	Storage temperature	-10~45°C
15	Over voltage warning/V	31.2V(15.6*2)
16	Over voltage alarm/V	32V(16.0V*2)
17	Under voltage warning/V	22.4V(11.2V*2)
18	Under voltage alarm/V	18.4V(9.2V*2)
19	Over temperature warning/°C	60°C
20	Over temperature alarm/°C	65°C
21	Regeneration function	Depend on Motor controller

contact sales11 AT ocelltech.com for more details.
