Quick Details

• Rated Load Capacity (KG):

  300

• Max Lift Height (mm)--H:

  2400

• Place of Origin:

  China

• Samples:

  Not Available

• Delivery Time:

  5-10 Days After Your Payment

• Packing:

  Carton Box, Plastic Bags, Wooden Cases Or As Your Requirement

• Delivery Port:

  Qingdao,Ningbo,Shanghai,Shenzhen

• Max. Production Capacity:

  1000sets

• OE Experience:

  No

Product Name:Semi-Automatic High Level Order Picker Price

Semi-Automatic High Level Order Picker Price

Application

china coal

Product Description:

chinacoal2
m.chinacoalintl.com Semi-automatic High Level Order Picker price Semi-automatic High Level Order Picker
high level order picker
Pickers
order picker
Electric High Level Order Picker
Product Description TH series semi-automatic high level order picker;
Rated load capacity: 300kg;
Max lift height: 3500mm, usually used in warehouse, library, supermarket rack etc;
The secure brake and bolt protective device, to ensure the safe operation.
Our range of Semi-automatic High Level Order Picker is fabricated by a team do dexterous professionals using the finest grade factor inputs and latest technology in compliance with the international standards. This product is broadly accepted by our clients due to their superior finish, durability, high load bearing capacity and longer service life without any hassles. Offered in various technical specifications, this range of order picker is available at the most reasonable prices.

Description Model No.	TH0324	TH0330
Operation Type	Stand-on	Stand-on
Rated Load Capacity (KG)	300	300
Max Lift Height (mm)--H	2400	3000
Max.Height-Rack (mm)--H1	3710	4010
Max.Height-Max (mm)--H2	2920	3220
Height-Mast Lowered(mm)-H3	1690	1990
Min.Height-Platform(mm)-H4	540	540
Min. Height-Stand Platform(mm)-H5	345
Min. Road Clearance (mm)-H6	195
Overall Length (mm)--L	1520
Wheelbase (mm)--L1	1025
Overall Width (mm)--W	890
Rear Tread (mm)--W1	686
Front Tread (mm)--W2	485
Body Width (mm) --W3	600
Front Wheel (mm)	150*50
Rear Wheel (mm)	180*50
Load Platform Size(mm)	600*600
Stand Platform Size(mm)	450*600
Min. Turning Radius(mm)Ra	1380
Lift Speed(mm/s)	85
Lift Motor	1.5
Battery-V/AH	12/120
