Bock compressor is used for bus air conditioner, it suitable for 7meters to 13.5 meters bus and double-decker bus.
Create a healthy,comfortable,environment friendly and fashionable travel environment.
Bock Compressor Technical Data
| Number of cylinders | 4 |
| Bore | 65mm |
| Stroke | 49mm |
| Swept volume | 650 cubic cm |
| Displacement(1450/3000 1/min) | 56.60/117.10 m3/h |
| Mass Moment of intertia | 0.0043kgm2 |
| Permissible range of rotation speeds | 500-3500 1/min |
| Max.permissible pressure(LP/HP)1) | 19/28 bar |
| Connection suction line SV | 35MM - 1 3/8" |
| Connection discharge line DV | 35MM - 1 3/8" |
| Lubrication | oil pump |
| Oil type R134a,R404A,R407C/F,R507 | FUCHS Reniso Triton SE 55 |
| Oil type R22 | FUCHS Reniso SP 46 |
| Oil charge | 2.0 Ltr |
| Net Weight | 32kgs |
| Gross Weight | 34kgs |
| Dimensions | 385*325*370mm |
| Packing Size |
