Product Name:ZJP Series Rotary Varactor Roots Vacuum Pump

ZJP Series Rotary Varactor Roots Vacuum Pump

Application

china coal

Product Description:

chinacoal12 m.chinacoalintl.com ZJP Series Rotary Varactor Roots Vacuum Pump

Vacuum Pump, Rotary Varactor Roots Vacuum Pump,ZJP Series Rotary Varactor Roots Vacuum Pump

Specifications

vacuum pump
1.pumping speed:70-1200L/S
2.Power:1.1-22kw

Introduction:

The pump consists of two figure “8” shaped rotors and two semicircular pump houses. The rotors rotate synchronously in

 opposite directions and high speeding. The pump cannot be used singly; it must be used as boosters combined with a backing

pump such as a rotary piston or a rotary vane vacuum pump, or a liquid ring vacuum pump. These vacuum systems can get higher

 vacuum, a stable, fairly high pumping speed can be gained in effective pressure range. The backing pump decides the ultimate

pressure of roots pump. The data of the list is lowest ultimate pressure with the standard equipment (equipped double stage oil machine vacuum pump).

The Roots pumps are widely used in vacuum moulding, vacuum smelting, vacuum gas pumping, vacuum coating industry, vacuum distilling and vacuum

drying of chemical and pharmaceutical industry etc. The pump is insensitive to a little dust.

Features:
1. The lack of reciprocating parts allows a perfect dynamic balancing, because the rotors is processed by numerical control machine tool and balanced carefully.
