Quick Details

• OE Experience:

  No

Product Name:Spring Brake Actuator 3530Z15-001/002

Spring Brake Actuator 3530Z15-001/002

Application

Eq3082 Eq4243 Series Air Brake Models

Product Description:

OEM No/Model: 3530z15-001/ 002
Product Name: Spring brake actuator 3530Z15-001/002

NO.: 3530Z15-001/002

Certification: ISO14001, GB/T28001, TS16949

Application:

The double diaphragm style spring brake actuator which create the force wheel braking .

They consist of the diaphragm part the spring brake part , the diaphragm section for the service brake system and the spring brake section for the secondary and parking system .

The diaphragm actuator section is completely independent in operation form the spring brake section.

Technical Features:

.Max.operating pressure 1000kPa

2.Operating pressure 800kPa

3.Perating pressure air

4.Temperature range -40~+80

5.Rescind pressure of spring brake part 500kPa

6.Operating stroke for the service brake 64mm

7.Operating stroke for the parking brake 64mm

8.Mechanically releasing torque 75 Nm

9.Type 30/30

Applicable Type of Vehicles: EQ3082EQ4243 Series Air brake models
