Quick Details

• Voltage:

  12V

• Display Size:

  220cm

• G.W:

  1.2kg

• Power:

  4w

• Screen Size:

  3.5" TFT-LCD

• Placement:

  Roof

• Combination:

  Bluetooth-Enabled MP3 / MP4 Players

• Certification:

  CE/FCC/ROHS/E-MARK

• Car STYLE:

  audijetta and volkswagen and so on,jetta and volkswagen and so on

• Place of Origin:

  Guangdong China (Mainland)

• Brand Name:

  OEM/GLOBAL MEDIA

• Appearance:

  similar with original car

• surface:

  black

• function:

  powerful

• skype:

  globalcarmedia15

• Email:

  sales22 at germid.cn

• Place of Origin:

  Guangdong

• Samples:

  Charge

• Delivery Time:

  In 3 To 10 Days After Payment

• Packing:

  Unit Dimension (L*D*H) 26.5*8*3.2 Qty Per Export Carton 10pcs Unit Packing: (L*W*H) 31*17.5*6.5cm Export Carton (L*W*H) 35.5*32.7*38cm

• Delivery Port:

  SHENZHEN

• Max. Production Capacity:

  10000 In 2 Weeks

• Export Ratio:

  91% - 100%

• OE Experience:

  No

Product Name:Newest Model Car Rearview Mirror With Car Interior Mirror With Auto-Dimming, Bluetooth

Newest Model Car Rearview Mirror With Car Interior Mirror With Auto-Dimming, Bluetooth

Application

any car model. such as the Toyota, Ford, Honda, BMW, Chevrolet, and Kia etc

Product Description:

OEM No/Model: DK-043RA
Technical Specification
1.Operating Voltage9.0 -16.0 Vdc
2.Operating Temperature-40oC ~ +85oC
3.Storage Temperature-40o C~ +100oC
4.Maximum Current<450 milliamps
5.High Reflectance>70%
6.Low Reflectance6~10%
7.Time to change reflectance from 55% to 15% at 25o<6.0 seconds
8.Time to change reflectance from 15% to 55%<8.0 seconds
9. They are hands off, no manual adjustments are required leaving the driver free to watch the road.
10. The are variably dimming, meaning they are continually dimming and clearing to the precise level necessary to optimize vision.
11. In the darkest state, the minimum reflectance is only 7% and increases from there depending on the glare conditions.
12 Auto-Dimming Mirrors use advanced Electrochromic technology providing maximum glare management.


After - sales service
1.Sample is available for further evaluation
2. Warranty: 1year
3.Offer long-term OEM/ODM service

Technical Specifications of Camera
1. Image device: 1/4-inch colour vc0702
2. TV system: NTSC
3. Resolution: 480 TV lines
4. Electric Shutter: NTSC :720Lines.25Field/sec
5. Effective pixels: NTSC: 720X 480
6. Minimum illumination: 0.3Lux
7. Viewing angle: 170 degrees (diagonal)
8. S/N ratio: >48dB (AGC-OFF)
9. Video output: RCA connector, 1.0vp-p, 75ohm
10. Current consumption: 120mA
11. Power supply: DC8V-12V
12. Operating temperature: -30 to 65 degrees centigrade, RH95% Max.
13. Storage temperature: -35 to 70 degrees centigrade, RH95% Max.
14. Other items: automatic white balance, AGC and BLC
15.Water-proof: Yes, to IP68 standard

Notice: You need to adjust the record of rear view image manually when you reverse the car
