Quick Details

• Rated voltage:

  DC 12V

• working voltage:

  9V-16V

• working current Imax:

  30A

• Static current:

  5mA

• Remote frequency:

  315MHZ+-5KHZ

• Remote distance:

  10m

• working temp controllor:

  -40-85degree

• Remote:

  -30-70degree

• Humidity:

  95%

• Place of Origin:

  Shenzhen,China

• Samples:

  Charge

• Sample Price:

  20

• Delivery Time:

  10-30days

• Packing:

  White Box

• Delivery Port:

  Shenzhen

• Max. Production Capacity:

  20000000000pcs/Month

• Export Ratio:

  81% - 90%

• OE Experience:

  No

Product Name:K19B Remote Controller

K19B Remote Controller

Application

any car

Product Description:

K18E RKE system

1. Technical parameters

1.1 Rated voltage: 12V DC.
1.2 Working voltage: DC 9V-16V.
1.3 Radio freqency: 315MHz.+-75KHZ
1.4 Remote controlling distance:<=10m
Absolutely effective: 30m;
Possibly effective: >30m.
1.5 Code quantity: 2 million
1.6 Working current:
Central locking: <20A;
Steering lamps: <15A.
1.7 Standy current: <10mA.
1.8 Flashing frequency of steering lamps:
Normal state: 85 times/min;
Alarming state: 85±5 times/min.
1.9 Working temperature:
Host controller: -40 ~ +85.
Remote controller: -30 ~ +70.
1.10 Woking humidity:95.
1.11 Battery: CR2016, 3V DC (Non-chargeable).

2. Features

1. Remotely control to lock or unlock.

2. Unlocking when the engine is off; locking when braking for the first time after starting the engine.

3. Locking automatically in 30 seconds after remotely unlocking but nobody gets in the vehicle.

4. Code learning.

5. Protection for successive locking/unlocking.

6. Reminding by flashing lights when opening the door.

Shenzhen Supa Industry Co., Ltd, established in 1994, specializes in developing, manufacturing and marketing Central Locking system, Remote Keyless Entry(RKE) system, Car DVR, Car Multifunction Jump Starter, Smart Key(Passive Keyless Entry) system, etc. Supa reached long-term R&D agreements ...[Read More]

Company Profile:

• Main Product:

  Central Locking system, Remote Keyless Entry(RKE) system, Car DVR, Car Multifunction Jump Starter, Smart Key(Passive Keyless Entry) system, Body Control Module

• Business Type:

  Manufacturer

• Current Export Market:

  North America, South America, Western Europe, Eastern Europe, Eastern Asia, Southeast Asia, Mid East, Africa, Oceania

• Total Annual Sales:

  USD 10,000,001 - 50,000,000

Factory Profile:

• Number of Employees:

  201 - 300 People

• Shift:

  1

• Size of Factory In Square Meters:

  8500

• Years of OEM Experiences:

  13

• Certification:

  TS16949

• Equipment Name:

  Wave Soldering Machine, Ultrasonic Welding, Ultrasonic Cleaning, Terminal Machine, SMT Machine, Hot Air Reflow Soldering, Aging Machine

Research & Development:

• Capability for Synchronized Development:

  Develop according to drawing or samples provided by clients?Yes

  Develop 3-D model and prototype according to client's needs?Yes

• Lead Time for New Product Development:

  1~3

• Tooling Design:

  Design Internally

• Source of Tooling:

  Made Internally

• Software/Profile:

  Unigraphics, AUTOCAD, Pro/E, Catia , Others
