Quick Details

• OE Experience:

  No

Product Name:Car DVD With 3G Internet

Car DVD With 3G Internet

Application

Volkswagen

Product Description:

Product nameCar DVD With 3G Internet
Item
Details
Car DVD With 3G Internet

Manufacturer Specifications
Volkswagen Edition - In Dash Car DVD With 3G Internet (WIFI, 2DIN, GPS, DVB-T)
Designed for Volkswagen Vehicles:
- Passat B6
- Passat B7
- Passat CC
- Jetta 2005-2008
- Golf 2003~2009
- Skoda Superb
- Tiguan
- Touran
Primary function: 2-DIN Car DVD Player with GPS, DVB-T, WIFI, and 3G Internet Access
Main system information
- Motherboard: Telechips TCC8900
- Core CPU: ARM 1176JZF-S (500MHz)
- GPU: ARM Mali-200 (200MHz)
- Internal memory: 256MB RAM, 256MB Nand Flash
- External memory: SDHC card (up to 32GB) and USB drive (up to 32GB)
- Default baud rate: 9600
- COM port: 2
- Operating system: Windows CE 6.0 GPS information
- Receiver module: MediaTek GS-92m-J
- Frequency: 1.575.42 GHZ
- C/A Code: 1.023 MHZ
- Signal channels: 32
- Tracking sensitivity: -157dBm
- Position sensitivity: 10m, 2D RMS; 5m, 2D RMS , WAAS enable
- Speed rate: 0.1m/s
- Data update rate: 1HZ
- Recapture time: Average 0.1s
- Hot startup time: Average 1s
- Warm startup time: Average 30s
- Cold startup time: Average 36s
- Maximum position altitude: 18000M
- Maximum speed rate: 515m/s
- Built-in antenna type: External power source porcelain antenna
- Built-in antenna voltage: 3.3V±5%
- Built-in antenna current: 6mA
- Built-in antenna gain: 27dB
- Interface: Touch screen
- GUI interface: YES - 3D type
- Maps: via SD card
- Voice: YES
- GPS menu languages: English (United Kingdom), English (United States), Mandarin Putonghua Chinese, Cantonese Chinese, Taiwanese Chinese, German, Croatian, French, Italian, Dutch, Spanish, Romanian, Portuguese (Portugal), Portuguese (Brazil), Swedish, Slovak, Slovene, Serbian, Flemish, Bulgarian, Ukranian, Polish, Latvian, Lithuanian, Kalba, Hungarian, Dutch, Danish, Norwegian, Finnish, Czech, Greek, Russian, Thai, Malay (Actual voice and display language depends on the GPS software being used) Internet information
- 3G: supports WCDMA 3G dongles and WCDMA 3G sim cards
- WIFI: 802.11 b/g (included) Display information
- Screen: 7 Inch TFT LCD
- Resolution: 800 x 480 RGB
- Picture in picture: YES
- Choose your own background pic: YES
- Tilt angle: 0-90 degrees (button activated motorized tilt)
- Video systems: PAL, NTSC, AUTO Disc information
- Region free (also known as region zero or no region)
- CD, VCD, SVCD, DVD, MP3, WMA DVD information
- Auto play: ON/OFF
- 16:9, 4:3 PS, 4:3 LB
- DVD menu languages: English, Chinese, German, Spanish, French, Portuguese, Latin, Italian DVB-T information
- Digital TV receiving standard: MPEG-2
- Automatic and manual search
- Display: 16:9, 4:3
- Languages: English, German, French, Italian, Spanish, Turkish, Greek, Russian, Czech, Slovak, Vietnamese, Chinese Audio information
- Max audio output: 45W x 4
- Signal-to-noise ratio (SNR): >85dB
- User adjustable EQ: Bass, Treble, Balance, and Fade AM/FM radio tuner information
- AM frequency range: 522~1710KHz (Worldwide)
- FM tuning range: 87.5~108.0MHz (Worldwide)
- RDS system: YES Bluetooth 2.1 Media player information
- Video formats supported (up tp 1080p): H.264, MPEG 1/2, MPEG 4, VC-1, Real Video 8/9/10, H.263
- Audio formats supported: MP3 / WMA / EAAC+ / AC3
- Image formats supported: JPG Connection information
- IPOD input
- USB input
- GPS antenna input
- DVB-T antenna input
- Radio antenna input
- RCA audio OUT x2 (front L and R)
- RCA audio OUT x2 (rear L and R)
- Aux-L IN
- Aux-R IN
- Subwoofer
- Video IN
- Video OUT x2
- Camera IN
- Left front speaker x2
- Right front speaker x2
- Left rear speaker x2
- Right rear speaker x2 Control information
- IR window
