Quick Details

• Combination:

  Built-in GPS

• Place of Origin:

  China (Mainland)

• Delivery Time:

  0

• Packing:

  giftbox with foam

• OE Experience:

  No

Product Name:AUDI A4/A5/Q5 Video GPS Interface

AUDI A4/A5/Q5 Video GPS Interface

Application

AUDI

Product Description:

1. It is for AUDI A4/A5/Q5 NON MMI system from 2004-2009
2. Built-in GPS Function, plug and play for NAVI GPS function

1.It is for 2005-2009 version
 2. For Non- MMI control system.
 3. Built-in GPS Funtion together.
 3. With two AV input and output, One RGBS, one rear camera input,  and LVDS input output synch
 4. Plug and play, can make your OEM and aftermarket monitor playing DVD, TV, camera, navigation, etc  all kinds of video units.
5.Built-in CANBUS, that can use the original button to switch the functions.
6.  Reverse auto. When your gear is in reverse, will auto to switch to rear camera.
7. Built-in FM transmittion, when you set Radio Channel FM87.9, then you can hear the sound of DVD, DVB-T from the original car speaker.

GPS Techincal Data:

1.  Main Control Processor: SiRF Atlas IV, and main frequency: 500MHZ2.  main storage: 64M ,128M (optional:DDR I)3.  Flash storage: 64M,128M,1G,2G (optional:Nand flash )4.  video output format: RGB,CVBS,YC,digital: RGB5655.  Synch signal: composite sync signal, and synchronizing signal separation6.  video output system: NTSC,PAL7.  video output resolution: 320X240,400X234,480X234,800×4808.  GPS antenna power: 3-5V9.  Operation system: WINCE.NET 6.0 Core Version10.  Input voltage: 5V-24V11.  Touching panel connection: 4PINS resistance touching function12.  Memory Card: SD/MMC/SDHC(SDHC)4GB~32GB
