Quick Details

• Video Systems:

  PAL

• OE Experience:

  No

Product Name:Car Backup Camera with Double Heads

Car Backup Camera with Double Heads

Application

Product Description:

OEM No/Model: TOP-211M-313M

Features:
1. )Double heads are changed each other in free
2. )OV- 7950 CMD, Super high effect
3. )420 TV Line
4. )90° / 120° View angle optional
5. )Waterproof IP66~67, Anti- Fog, Anti- Shock
6. )with reversing reference line: Optional
7. )OV- 7949, PC1030 sensor optional

Specifications:
1. )Number of Pixels: NTSC: 512(H)*492(V); PAL: 628(H)*582(V)
2. )Horizontal Resolution: 420 TV Lines
3. )Waterproof Resistance: IP67~68
4. )Auto Gain Control: Auto
5. )Usable Illumination: 0. 1 Lux(F: 1. 2)
6. )Video Output: 1. 0Vp- P 75Ω , Negative
7. )Electronic Shutter Time: Auto: NTSC 1/ 60- 1/ 100, 000Sec, PAL 1/ 50- 1/ 100, 000Sec
8. )Operation Temperature: - 20℃~ +60℃ RH 95% Max
9. )Storage Temperature: - 40℃~ +80℃ RH 95% Max
10. )Gamma Characteristic: 0. 45
11. )90° / 120° Wide view angle
12. )White Balance: Auto
13. )Scanning System: NTSC 525 Lines, 60Field/ Sec, PAL 625 Lines 50Field/ Sec
14. )Sync System: Internal Synchronization
15. )Power Supply: DC12V± 10%, 40mA

Accessories:
Extram head, 5m video cable, DC Power cable, User mamual


Topccd manufactur specially security products for many years. Our main products are Our main products are Vehicle rear view system, Rear view camera, Rear view monitor. Topccd products are applying the wide area such as department store, Ship, Boat, Farm, House, Supermarket, Factory, School. . ...[Read More]

Company Profile:

• Main Product:

  Vehicle Rear View System, Rear View Camera, Rear View Monitor.

• Business Type:

  Manufacturer

• Current Export Market:

  North America, South America, Western Europe, Eastern Europe, Eastern Asia, Southeast Asia, Mid East, Africa, Oceania

Factory Profile:

• Number of Employees:

  51 - 100 People
